BBA Agrément Certificate
EPDM waterproof membrane, factory pre-fabricated into large areas.
A pre-fabricated EPDM waterproof membrane suitable for forming ballasted, adhered or mechanically fixed, single ply roofs on new build and refurbishment projects.
Rolls of EPDM are thermally bonded in the factory to form large membranes, with a maximum weight of 2500 kg and a maximum size of 2,000 m². Roofs can thus be rapidly waterproofed, with no seams being formed on the roof.
Properly installed the system has a life of at least 35 years.
easy cover is suitable for use on concrete and timber-based substrates, as well as insulation boards laid over profiled metal sheet, and existing bituminous roof coverings.
– Vapour control layers:
Depending on internal conditions a vapour control layer may be required: consult Hertalan (UK) for details.
– Separation/ Protection layers:
Where easy cover is mechanically fixed a separating layer of Hertalan easy tex may be required to prevent the membrane 'drumming' on the substrate or damaging EPS insulation board.
In inverted roof systems the membrane should be protected from the ballast by a layer of easy.tex.
Where easy cover is to be installed over an existing bituminous waterproof covering with embedded chips consider using two layers of easy tex, or a thin mineral wool or EPS insulation board.
easy cover should be fixed along the whole perimeter with ks137, ks205 or ks96 adhesive.
J42/10 Warm deck roof covering
J42/110 Warm deck roof covering
J42/120 Inverted roof covering
J42/130 Cold deck roof covering
easy cover FtS
easy cover MF
Insert dimensions or refer to drawing.
easy cover rainwater outlets
easy cover roof drains
easy.weld CS – 100 mm
easy.weld CS – 150 mm
easy.weld CS – 200 mm
Maximum dimensions 10 m x 20 m for easy cover MF, 30 m x 70 m for other types.
All grades available 1.2, 1.5 and 2.0 mm.
