Description

Toilet cubicles available in a wide range of materials including particleboard, laminates, veneer, glass, pattered glass and cast Acrylic.

General information
Material

As schedule ___

A wide range of materials available, please contact manufacturer for details.

Size

2040 mm overall height including 150 mm floor clearance

Uniclass 2015 Panel cubicle systems (Ss_25_12_60_60)
Specification data
Product Reference

Duet Toilet Cubicle

Type

DuetG

Glass doors.

DuetGhpl

Glass doors with laminate partitions.

DuetGsgl

Glass doors with solid grade laminate partitions.

DuetGv

Glass doors and real wood veneer partitions.

DuetHPL

Laminate doors.

DuetMFC

MFC doors.

DuetSGL

Solid grade laminate doors.

DuetV

Real wood veneer doors.

Material

As schedule ___

A wide range of materials available, please contact manufacturer for details.

Colour

As schedule ___

Edge treatment

Lipped with corresponding PVC

DuetGhpl, DuetHPL and DuetMFC.

Lipped with matching laminate

DuetGhpl, DuetHPL and DuetMFC.

Manufacturer's standard

Pilaster finish

Manufacturer's standard

Other finishes available upon request subject to surcharge.

As schedule ___

Legs

Not required

Required

Standard product features

Size:

2040 mm overall height including 150 mm floor clearance.

Headrail:

Satin anodized aluminium aerofoil profile to match pilasters.

Ironmongery:

Satin polished Grade 316 stainless steel channel bracket partition and pilaster fixings.

Product Options

Type:

- Glass doors (DuetG):

  • Panels: 6 mm toughened and screen printed safety glass bonded to 13 mm thick solid grade laminate.
  • Doors and partitions: 10 mm toughened and screen printed safety glass.

- Glass doors with laminate partitions (DuetGhpl):

  • Panels: 6 mm toughened and screen printed safety glass bonded to 13 mm thick solid grade laminate.
  • Doors: 10 mm toughened and screen printed safety glass.
  • Partitions: 18 mm MR MDF faced on both sided with high pressure laminate (HPL).

- Glass doors with solid grade laminate partitions (DuetGsgl):

  • Panels: 6 mm toughened and screen printed safety glass bonded to 13 mm thick solid grade laminate.
  • Doors: 10 mm toughened and screen printed safety glass.
  • Partitions: 12/ 13 mm solid grade laminate (SGL).

- Glass doors and real wood veneer partitions (DuetGv):

  • Panels: 6 mm toughened and screen printed safety glass bonded to 13 mm thick solid grade laminate.
  • Doors: 10 mm toughened and screen printed safety glass.
  • Partitions: 18 mm MR MDF faced on both sided with real wood veneer.

- Laminate doors (DuetHPL):

Panels, doors and partitions: 18 mm MR MDF faced on both sides with high pressure laminate (HPL).

- MFC doors (DuetMFC):

Panels, doors and partitions: 19 mm moisture resistance (MR) melamine faced chipboard (MFC).

- Solid grade laminate doors (DuetSGL):

Panels, doors and partitions: 12/ 13 mm solid grade laminate (SGL).

- Real wood veneer doors (DuetV):

Panels, doors and partitions: 18 mm MR MDF faced on both sides with real wood veneer.

- Colour:

To be confirmed from WW standard range, subject to depth of partition.

Edge treatment:

  • Glass doors (DuetG): All edges polished.
  • Glass doors with laminate partitions (DuetGhpl): Edges lipped with matching laminate or corresponding PVC.
  • Glass doors with solid grade laminate partitions (DuetGsgl): Exposed edges machined to a smooth finish.
  • Glass doors and real wood veneer partitions (DuetGv): All edges polished.
  • Laminate doors (DuetHPL) and MFC doors (DuetMFC): Edges lipped with matching laminate or corresponding PVC.
  • Solid grade laminate doors (DuetSGL): Exposed edges machined to a smooth finish with radiused safety corner details to doors.
  • Real wood veneer doors (DuetV): All edges lipped in corresponding hardwood, vertical edges to run through.

Pilaster finish:

Split pairs of elliptical/ aerofoil aluminium pilasters 100 x 40 mm. Satin anodized as standard. Other finishes available upon request subject to surcharge.

Legs:

Two options available:

  • Tubular and rounded off design manufactured from satin anodized aluminium, fixed to partition panel. Adjustable to suit uneven floor levels.
  • Not required as main pilaster extended to floor.
