DropTile Speckle - Indoor rubber sports flooring
Verified by manufacturer 3 months ago
SCS Certified
Certificate type
Droptile speckle for all types of free weights areas.
Application
Commercial applications such as gyms, schools and sports facilities.
Description
Droptile speckle for all types of free weights areas. With a superior resistance to impacts and falling of heavy loads (up to 200kg) thanks to its 30 mm 3-layers composition, with extra high density top layer. It is suitable for installations in upper floors thanks to its vibrations reduction performance.
Features and benefits:
- Adhesive-free for easy installation.
- Good acoustic performance.
- High impact resistance.
- Eight connector pins per tile.
- Reinforced backing.
General information
Color | Blue Grey Red |
Finish | Smooth |
Material | Rubber |
Shape | Rectangle |
Length | 1000 mm |
Width | 500 mm |
Height | 30 mm |
Warranty description | Three year |
Uniclass | |
CAWS | M50/10 Resilient floor tiling M50/110 Resilient floor tiling |
Specification data - Rubber tiles
Standard | To ISO 24346, ISO 23997, ISO 24341, EN 14808, EN 12235, EN 13501-1, EN ISO 1798, DIN 53505, DIN 53516, EN 13893, EN 13036-4, ISO 10140-3. |
Properties | |
Dimensions | |
Depth | 30 mm. |
Plan size | 500 x 1000 mm. |
Backing layer | |
Material | Rubber. |
Colour | 430009104 Droptile speckle blue 30 mm.430009103 Droptile speckle dark grey 30 mm.430009101 Droptile speckle light grey 30 mm.430009102 Droptile speckle medium grey 30 mm.430009105 Droptile speckle red 30 mm. |
Installation | Loose-Lay. |
Reaction to fire | Cfl-s1. |
Weight | 27 kg/m². |
Packing | Manufacturer guidance80 tiles per box, 40 m² per box. |
Shock absorption | 45%. |
Ball rebound | 95%. |
TensileStrength | 0.7N/mm². |
Elongation at break | 70%. |
Hardness | 60 ± 5 Shore A. |
TemperatureRange | -30°C to 80°C. |
Abrasion resistance | 450 mm³. |
Static coefficient of friction | > 0.3 μ (DS). |
Impact sound reduction | 24 dB. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United States |
Recyclability | 0 |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
Third party certifications
SCS Certified
VOC - Floorscore - Tarkett Droptile & Dropzone
