CVRock Rainscreen Slab - Rock Wool Slab Insulation
Verified by manufacturer 27 days ago
50 mm Slab
50 mm Slab
Slabs of stone wool for internal and external building objects for thermal, acoustic and fire insulation.
Application
Suitable for use in applications such as:
- External facades insulated by lightweight cladding (e.g. rainscreen, composite, siding or lining cement).
- External walls with facades of stone or glass.
- Exterior and interior stud walls (wood and metal framework).
- Brick cavities, curtain walls, cavity walls, partition walls, suspended ceilings and soffits.
Description
Mineral wool slab for internal and external thermal, acoustic and fire insulation.
Features and benefits:
- Rigid 1200 x 600 x 50–250 mm slab.
- A1 reaction to fire.
- Range of thicknesses.
- Thermal conductivity: ≤0.034 W/m·K.
- Thermal resistivity: 1.45–7.35 m²·K/W.
General information
Color | Yellow |
Finish | Unfinished |
Material | Mineral wool |
Shape | Rectangle |
Length | 1200 mm |
Width | 600 mm |
Height | 50 mm 60 mm 70 mm 80 mm 90 mm |
Uniclass | |
CAWS | H92/775 Thermal insulation F30/12 Partial fill cavity insulation H31/50 Thermal insulation K45/50 Insulation F30/10 Full fill cavity insulation F30/155 Partial fill cavity insulation K40/55 Insulation K45/425 Insulation K40/285 Insulation F30/150 Full fill cavity insulation H30/311 Mineral wool thermal insulation H31/271 Mineral wool thermal insulation |
Specification data - Mineral wool slab insulation
Classification data | |
Standard | To BS EN 13162. |
Thickness | 50 mm. |
Edges | Square. |
Thermal conductivity (maximum) | ≤0.034 W/m·K. |
Compressive strength (minimum) | 20 kPa. Guidance for specification option: At 10% deformation. |
Fire performance | Reaction to fire classification of A1, as defined in BS EN 13501-1. |
Thermal resistance | 1.45 m²·K/W. |
Tensile strength | ≥7.5 kPa. Guidance for specification option: Tensile strength perpendicular to face. |
Sustainability data
Material | Mineral wool |
Literature
Literature type
TDS - CVRock Rainscreen Slab
Instruction for use and handling of Coverock stone mineral products
