CounterShield
Verified by manufacturer 3 days ago
Anti-physical attack sash style security window.
Application
Typical applications include A&E and hospital reception desks, local authorities, police and schools.
Description
CounterShield is an anti-physical attack sash style security window, designed to facilitate open counter trading and staff protection. The ability to set the electrically driven moving screen at any position between fully open and fully closed allows staff protection to be varied in the face of changing risk or for a position to be temporarily closed as required.
Features and benefits:
- Fits to existing counterwork.
- Ability to electronically drive the screen to any position from fully open to fully closed.
- Can be quickly closed by a panic button on the staff side.
- Safety beam across leading edge of the screen to prevent being trapped by the moving screen.
- Requires 240 V.a.c., 5 A power.
- Nationwide installation and service contracts available.
- Where multiple Countershields are installed, the system can be supplied so that pressing any of the reactive closure buttons will close all of the screens.
- Framework finish can be polyester powder-coated to match surrounding environment.
- Standard and bespoke sizes are available.
General information
Color | Clear White Grey Black Other |
Finish | Powder-coated |
Material | Steel Glass Polycarbonate |
Shape | Rectangle |
Width | 900 mm 1200 mm Bespoke |
Height | 1300 mm 1500 mm 1700 mm Bespoke |
Uniclass | |
CAWS | L10/60 Security L10/690 Security H14/340 Security window panels |
SKU Code | DA290011 |
Specification data - Glazed security window panels
Classification data | |
Panel configuration | Standard. |
Third party product certification | Accreditation by the United Kingdom Accreditation Service (UKAS). |
Panel size | |
Overall size (width x height x depth) | Manufacturer guidanceConsult manufacturer and insert requirements.
|
Glazing configuration | Single glass block. |
Glazing units | |
Type | Block. |
Standard | To BS EN 356, P4A. |
Colour | Natural. |
Frame finish | Polyester powder-coated. |
Operation | Electronically driven (requires 240 V.a.c., 5 A power). |
Sustainability data
Material | Steel Glass Polycarbonate |
