Description

Cast aluminium half round gutter system.

  • Approximates to traditional half round cast iron systems.
  • Choice of sizes.
  • Bracket fix to fascia or to rafters. Secure using stainless steel screws.
  • Jointing: Spigot and socket, bedded in silicone mastic and secured using stainless steel bolts.
  • Powder coated finish applied inhouse. Consult manufacturer for choice of colour. Thirty year guarantee available on application, subject to location.
  • Compatible downpipes listed separately.

General information
Finish

Anodized, colour ___

Nonstandard option.

Interpon D, colour ___, gloss level ___

Polyester powder coating. Standard option.

___ Powder coating, colour ___, gloss level ___

Non standard option.

PVDF, colour ___

Nonstandard option.

Uniclass 2015
External gravity rainwater drainage systems (Ss_50_30_02_28)Primary
Specification data - External gravity rainwater drainage systems
Product Reference

Corfe Gutter

Layout

As drawing ___

SectionWidth

100 mm

113 mm

125 mm

150 mm

Outlet

63.5 mm diameter

76 mm diameter

102 mm diameter

For section width 150 mm only.

Finish

Anodized, colour ___

Nonstandard option.

Interpon D, colour ___, gloss level ___

Polyester powder coating. Standard option.

___ Powder coating, colour ___, gloss level ___

Non standard option.

PVDF, colour ___

Nonstandard option.

Other requirements

External angle 90 º

Internal angle 90 º

External angle 135 º

Internal angle 135 º

Fascia brackets

Use at 0.9 m centres.

Internal joint sleeve

Use to connect gutters without sockets.

Rafter brackets, side fix

Rafter brackets, top fix, pitch ___ º

Stop end

External/ Internal.

Standard product features

Handing:

Socket installed to left when viewing the building.

Plain gutter length:

1.83 m, modular. Actual length includes socket for overlap.

Running outlet length:

148 mm. Actual length includes two sockets for overlap.

Finish:

– Standard polyester powder coating: Interpon D1036, standard colour range.

  • Electrostatically applied to BS EN 12206 and Qualicoat Class 1 standards.
  • Compliant to ECHA standards which includes Chrome Free solution.
  • Film thickness: 60µ (minimum 50µ).

Product Options

Section:

Indicative flow rates (maximum with central outlet): Roof areas are indicative maxima. Suitable outlet interval varies with local climate and other factors. Consult manufacturer.

– Gutter section 100 mm diameter.

  • Outlet size 63 mm diameter. Flow rate at outlet: 1.1 L/s. Roof area: 53 m².

– Gutter section 113 mm diameter.

  • Outlet size 63 mm diameter. Flow rate at outlet: 1.56 L/s. Roof area: 75 m².

– Gutter section 125 mm diameter.

  • Outlet size 76 mm diameter. Flow rate at outlet: 1.86 L/s. Roof area: 90 m².
