CMSDA Smartfloor 28WF - Fibre-Reinforced Gypsum Floor Boards

Verified by manufacturer 8 days ago

CMS Danskin Acoustics

Medium density gypsum fibre panel bonded to a wood fibre layer providing excellent impact and airborne acoustic performance.

Jump to:
+44 (0)1925 577711 Website

Application

Suitable for flooring applications over solid substrates or joists with a minimum of 18 mm subfloor.

Description

Medium density gypsum fibre panel bonded to a wood fibre layer providing excellent impact & airborne acoustic performance.

Features and benefits:

  • 28 mm overall thickness.
  • Drop and slot profile.
  • High acoustic performance.
  • Easy to install.
  • Easy to cut and work.
  • Can accept direct bonded ceramic finish.
  • Can take light traffic after 4 hours.
  • Fully loaded after 24 hours.

General information

Color

Pink

Finish

Smooth

Material

Gypsum

Shape

Rectangle

Length

1200 mm

Width

600 mm

Height

28 mm

Uniclass

Pr_25_71_35_30 Fibre-reinforced gypsum floorboardsPrimary

CAWS

K11/275 Acoustic separating floor system

K11/295 Floating floor system

K11/60 Board

Specification data - Fibre-reinforced gypsum floorboards

Thickness

28 mm.

Guidance for specification option:

  • Top: 18 mm medium density gypsum fibre panel.
  • Bottom: 10 mm wood fibre layer.

Edges

Tongued and grooved.

Board size

1200 x 600 mm.

Sheet weight

16–17.4 kg.

Hardness

Brinell ≥20 N/mm².

Bond strength

≥0.6 N/mm².

Guidance for specification option:

Pull off bond strength.

Water absorption

To EN 20535, ≤300 g/m².

Manufacturer guidance

Surface water absorption.

Water vapour diffusion resistance

µ17

Manufacturer guidance

Value of vapour diffusion resistance

ThermalConductivity

0.38 AR W/m·K.

Mass per unit area

22.3–24.1 kg.

Manufacturer guidance

Mass per m².

Accessories

Karma perimeter strip.

Mineral wool edge strip.

Single layer joint adhesive.

Regupur® Reguprime primer.

Regupur® Regulevel 2 – smoothing compound before installing LVT/ Vinyl.

Show more

Sustainability data

Material

Gypsum
