Close Weave Mesh - Permeable Geotextile
Verified by manufacturer 3 months ago
Permeable geomembrane for ArborFlow tree pits.
Application
- Permeable geotextile for Arborflow tree pits is selected specifically to meet permeability objectives required for GBU Arborflow SuDS tree pits using RootSpace and ArborCell systems.
- Used beneath the ArborCell layer.
Description
GBU permeable geotextile for Arborflow tree pits is sourced specifically to meet permeability objectives required for GBU Arborflow SuDS tree pits using RootSpace and ArborCell systems.
GBUCWMA is used between the ArborCells and the soil cells. Water entering the tree pit from the road can frequently enter with volume and force, threatening localized erosion within the tree pit, GBUCWMA below the ArborCell helps eliminate the erosive force of the water and permit gentle infiltration into the soil across the entire tree pit.
Features and benefits:
- 1 m wide rolls up to 100 m long.
- Structural wall consisting of high strength woven strands.
- High strength non-woven wall keeps aggregates infiltrating rooting zones.
- Structural grade geotextile suitable for the highest loading situations.
General information
Color | Black |
Finish | Woven |
Material | Polypropylene |
Shape | Other Guidance for specification option: Roll. |
Length | Bespoke 100000 mm Guidance for specification option: Max roll length. |
Width | 1000 mm |
Uniclass | |
CAWS | Q20/170 Geotextile filter/ separator membrane Q25/64 Geotextile sheet Q25/365 Geotextile sheet D20/58 Geotextile sheet D20/550 Geotextile sheet |
Specification data - Polymeric membranes
Material | Polypropylene (PP). |
Performance characteristics | |
Watertightness | To DIN EN ISO 11058, 5 x 10-3 m/s. |
Tensile properties | To DIN EN ISO 10319, ≥30 (MD); ≥30 (CMD). |
Recycled content | None permitted. |
Integral backing fleece | Not required. |
Width (minimum) | 100 mm. |
Thickness (minimum) | Manufacturer's standard. |
Colour | Black. |
Accessories | Manufacturer guidanceConsult manufacturer and insert requirements or omit. |
Mass | To DIN EN ISO 9864, 160 g/m². |
Puncture resistance | To DIN EN ISO 12236, N ≥3.150 (x-s). |
Opening size | To DIN EN ISO 12956, 230 µm. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Material | Polypropylene |
Literature
GBUCWMA - Permeable Geotextile for Arborflow Tree Pits
