Cantifix Structural Glazing

Name: Cantifix Structural Glazing
Brand: Cantifix Ltd
SKU: kuu2xsWykABorYNKshNJmn

Verified by manufacturer 20 hours ago

Structural glazed - multi-sided enclosures

Cantifix Ltd

Product certifications:

CWCT Certificate
Certificate type

Structural glass rooflights and structures with a clean frameless appearance.

Jump to:

Request BIM

+44 (0)20 8203 6203 Website

Application

Rooflights, Walls, Facades, Floors and complete enclosures

Description

Structural glass rooflights and structures with a cleanframeless appearance.

Features and benefits:

Frame constructed of thermally broken (or thermally isolated) powder coated aluminium profiles with fully cleated, or welded, corners.
Standard clear double-glazed units with low-E coating to give a minimum centre pane U-value of 1.1 W/m²K (or 1.0 W/m²K with solar control).
All glass is classified as safety glass, in either toughened [HST] or heat-strengthened laminate with ground edges.
Secondary edge seals in silicone and with black TGI spacer bars.
Options include low iron glass (on non-coated panes), solar control coatings, along with acoustic or security interlayers.

General information

Color	Clear Guidance for specification option: Glass. Other Guidance for specification option: Framing.
Finish	Powder-coated
Material	Glass Aluminium
Shape	Rectangle Circle Elliptical Oval Trapezium
Length	Bespoke
Width	Bespoke
Height	Bespoke

Uniclass	Pr_30_59_72_31 Framed rooflightsPrimary Pr_25_71_33_42 Insulated glass units (IGUs)
CAWS	L10/460 Rooflights L10/45 Rooflights

Specification data - Framed rooflights

Classification data
Form	Multi-sided enclosure.
Size	Guidance for specification option: Insert requirements. Unsupported spans up to 6 m.
Product performance	-
Whole window U-value	To BS EN 10077, 1.4 W/m²K (maximum). 1.1 W/m²K (centre pane, minimum) or 1.1 W/m²K with solar control. Guidance for specification option: Consult manufacturer for details based on related details, or U-value requirements.
Frame	-
Material	Aluminium. Manufacturer guidance A combination of thermally broken aluminium profile with fully cleated corners and steel profiles depending on the dimensions. Fully assembled and thermally isolated with Nylon and XPS insulation.
Finish	-
Coating	Powder coating.
Colour	Guidance for specification option: Insert requirements; powder coated in any standard RAL colour.
Film thickness (minimum)	Manufacturer's standard.
Glazing or infill	-
Type	Toughened safety glass. Heat-strengthened laminate safety glass. Other. Guidance for specification option: Consult manufacturer for alternatives and insert requirements. Options include low iron glass, along with acoustic or security interlayers. See Coatings for further options.
Construction	Double glazed, standard. Double glazed, low iron glass. Double glazed with acoustic interlayers. Double glazed with security interlayers.
Colour	Clear.
Coating	Low-E to achieve minimum centre pane U-value of 1.1 W/m²K. Guidance for specification option: Standard. Solar control to achieve minimum centre pane U-value of 1.0 W/m²K. None.
Operation	-
Type	Not applicable.
Control	Not applicable. Guidance for specification option: Standard, belt-driven by synchronised electronic motors controlled through central Printed Circuit Board (pcb). The whole 24 V system is designed to be 'plug and play'. Manufacturer guidance An uninterrupted power supply (UPS) is achieved by installing a battery backup to allow for operation even during power outage.
Air permeability	To BS EN 12207, AE / 900 Pa.
Resistance to wind load	To BS EN 12210, Serviceability +/-2400 Pa; Safety +/-3600 Pa.
Watertightness	To BS EN 12208, RE / 900 Pa.
Performance characteristics	CWCT classification (TN92) horizontal: Class 2 (if four-edge supported and panels <4.5 m²).
