Verified by manufacturer 2 months ago
114 mm
A range of half-round gutters, manufactured from cast iron.
Suitable for listed building, heritage and conservation projects.
Britannia cast iron beaded half round gutters are available in various sizes and are supplied with a complete range of accessories such as angles, outlets, stop ends and various brackets. True radius gutters are also available on request.
Cast Iron gutters and rainwater pipes are the traditional choice for durable and aesthetically pleasing rainwater systems. It is still manufactured in the same shapes and sizes as 100 years ago, making it suitable for replacing existing cast iron products on heritage and listed building projects.
Features and benefits:
Color | Black Other |
Finish | Painted |
Material | Cast iron |
Shape | Other |
Length | 1830 mm |
Width | 114 mm 125 mm |
Height | 60 mm 65 mm |
Uniclass | |
CAWS | R10/12 Cast iron gutters R10/315 Cast iron gutters |
Standard | To BS 460. |
Profile | Half-round. |
Size (nominal) | 114 mm. |
Joint type | Socketed. |
Finish | Mill.Powder coating. |
Colour | Manufacturer guidancePolyester powder-coating is available in RAL or BS standard colours. Consult manufacturer and insert requirements. |
Integral accessories | BI/BHR45/A/90 - 90° Universal Angle.BI/BHR45/A/120 - 120° Universal Angle.BI/BHR45/A/135 - 135° Universal Angle.BI/BHR45/RO/25 - Running Outlet (Ø2.5”).BI/BHR45/RO/30 - Running Outlet (Ø3”).BI/BHR45/DE/25/E - Dropend Outlet External (Ø2.5”).BI/BHR45/DE/30E - Dropend Outlet External (Ø3”).BI/BHR45/DE/25/I - Dropend Outlet Internal (Ø2.5”).BI/BHR45/DE/30I - Dropend Outlet Internal (Ø3”).BI/BHR45/SE/EX - Stopends External.BI/BHR45/SE/IN - Stopends Internal.BI/BHR45/UC - Union Connector.BI/BHR45/FB/CI - Fascia Bracket.BI/BHR45/RB/TF - Top Fix Rafter Bracket.BI/BHR45/RB/SF - Side Fix Rafter Bracket.BI/BHR45/R&F/GS - Rise and Fall Bracket.BI/BHR45/R&F/WS - Rise & Fall Bracket with Stay. |
Length | BI/BHR45/6FT - 1830 mm. |
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Material | Cast iron |
Recyclability | Can be recycled at the end of its useful life |
Expected Life | 100 year |
