Bituminous Membrane System for Roof Gardens - IKO Roofgarden Torch-On

Name: Bituminous Membrane System for Roof Gardens - IKO Roofgarden Torch-On
Brand: IKO Ireland
SKU: tR1niqfznMBh9ibtyc2JuR

Verified by manufacturer 5 days ago

IKO Ireland

Product certifications:

NSAI Agrément Certificate
Certificate type

A torch-applied reinforced bitumen membrane system for roof gardens.

Jump to:

+353 1 88 55 090 Website

Application

Suitable for new build and refurbishment applications.

Description

IKO Roofgarden is used as the top layer to reinforced bitumen membrane systems, or as the final layer to an IKO Permatec monolithic membrane when installing roof garden finishes above. It has a dark slate colour finish on the upper surface and a thermofusible film on the underside. IKO Roofgarden can be used with IKO approved specifications in both extensive and intensive roof garden situations.

Features and benefits:

Achieves FLL four-year root penetration test.
Purpose-made roof garden waterproofing cap sheet.
Specifically formulated anti-root coating.
Flexible down to minus 20°C.
Excellent adhesion to substrate.

General information

Color	Grey
Material	Bitumen Polyester
Length	7500 mm
Width	1000 mm
Warranty description	Ten year 15 year 20 year

Uniclass	Ss_30_40_30_72 Reinforced bitumen membrane warm roof covering systemsPrimary
CAWS	J41/400 Built-up reinforced bitumen waterproof covering J41/10 Reinforced bitumen membrane warm deck roof covering J41/110 Built-up reinforced bitumen membrane warm deck roof covering

Specification data - Reinforced bitumen membrane warm roof covering systems

Classification data
Preparation	-
Horizontal work	IKOpro Sprayfast MPP. IKOpro Bonding Agent. IKOpro Quick Dry Bitumen Primer. Manufacturer guidance Deck priming is required. Product selection depends on the air and vapour control layer application method and deck type. Consult manufacturer and insert requirements.
Skirtings and vertical work	IKOpro Sprayfast MPP. IKOpro Bonding Agent. IKOpro Quick Dry Bitumen Primer. Manufacturer guidance Deck priming is required. Product selection depends on the air and vapour control layer application method and deck type. Consult manufacturer and insert requirements.
Air and vapour control layer	-
Type	IKO Ultra S-A Air & Vapour Control Layer. IKO Ultra T-O Air & Vapour Control Layer. Guidance for specification option: Unsuitable for timber substrates.
Attachment	Self-adhesive. Guidance for specification option: IKO ultra S-A air and vapour control layer. Torch-on. Guidance for specification option: IKO ultra T-O air and vapour control layer. Unsuitable for timber substrates.
Insulation	-
Type	Unilin FR MG Insulation, 1200 x 1200 mm. Unilin TR MG Insulation.
Fixing	Adhered with IKOpro PU Insulation Adhesive. IKOpro Sprayfast IBA.
Overlay	-
Type	IKO Ultra T-O Underlay.
Fixing	Torch-applied.
Waterproof covering	-
Top layer	-
Type	IKO Roofgarden Capsheet.
Attachment	Torch-applied.
Outlets	IKO Elite Outlets.
