Bilco Drainage Doors J-AL Single Leaf - J

Pit and Floor Door, Type J-1 AL

Bilco UK Variant:

Single leaf drainage door.

Jump to:
+44 (0)1284 701696 Website

Application

Designed for use in exterior applications or in those situations where there is concern of water or other liquids entering the access opening.

Description

A range of single leaf drainage doors designed for use in exterior applications or in those situations where there is concern of water or other liquids entering the access opening. These units are supplied with a threaded drain coupling, fully welded to the channel frame, for connection to a dry or wet well in the field.


The doors are constructed of 6.35 mm aluminium diamond pattern plate and reinforced for a 1464 kg/m² live load; and features all anti-corrosion hardware, standard debris gasket and a versatile anchoring system for ease of installation.


Features and benefits:

  • 38 mm drain coupling welded beneath the frame.
  • Heavy-duty construction and positive latching mechanism help to prevent unauthorized access.
  • Adjustable anchor tabs.

General information

Finish

Mill

Material

Aluminium

Shape

Square

Rectangle

Length

610 mm

760 mm

915 mm

1065 mm

Width

760 mm

915 mm

1065 mm

1220 mm

1525 mm

Show more

WarrantyDescription

Manufacturer warranty.

-

Uniclass

Pr_30_59_36_30 Floor hatchesPrimary

CAWS

L20/60 Doors

L20/630 Hatches

Product range

Pits and Floor Doors

Specification data - Floor hatches

Door

-

Orientation

Horizontal.

Material

Aluminium.

Dimensions

610 x 610 mm.

Weight

30 kg.

Digital objects

Platform Compatible Version Certified to
IFC

IFC2X3

2

1.3
Revit

Revit 2016

3

2.0
Download now from NBS National BIM Library
