BEWI Jackodur® EVO 300 Inverted Roof Insulation - Thermal Insultation
Verified by manufacturer 27 days ago
40 mm thick
40 mm thick
Extruded polystyrene foam (XPS) insulation available 40–400 mm thick and suitable for flat/ inverted roofs.
Application
For flat/ inverted roofs.
Description
BEWI Jackodur® EVO 300 Inverted Roof is the new generation of XPS using CO2 and multilayer manufacturing technologies delivering insulation characteristics with a declared (λD) 0.032 W/m·K.
BEWI Jackodur® EVO 300 Inverted Roof Insulation is manufactured in accordance with BS EN 13164 under a Quality Assurance System approved to ISO 9001 and Environmental Management System to ISO 14001.
Features and benefits:
- BBA Certified (21/5944 Product Sheet 4) Pending.
- Thicknesses 40–400 mm.
- Installed quickly and securely in a single layer.
- Suitable for zero fall roofs and roof terraces.
- Applicable to new and existing buildings.
- High compressive strength.
- Resistant to the effects of freeze/ thaw.
General information
Color | Purple |
Finish | Smooth |
Material | Extruded polystyrene (XPS) |
Shape | Rectangle |
Length | 1250 mm |
Width | 600 mm |
Height | 40 mm 50 mm 60 mm 80 mm 100 mm Manufacturer guidanceThickness. |
Uniclass | |
CAWS | M10/40 Floating construction M13/40 Floating construction J41/26 Thermal insulation J21/410 Expanded polystyrene insulation J21/25 Warm deck roof insulation Q37/110 Intensive green roofs J31/331 Expanded polystyrene (EPS) insulation M21/210 Rendered external wall insulation systems J41/410 Expanded polystyrene (EPS) insulation E20/30 Underslab insulation J42/27 Thermal insulation Q37/310 Inverted roof insulation J42/410 Expanded polystyrene (EPS) insulation M13/260 Floating construction M10/290 Floating construction J31/26 Thermal insulation E20/200 Proprietary underslab insulation M21/20 External wall insulation systems |
Specification data - Extruded polystyrene (XPS) boards
Classification data | |
Standard | To BS EN 13164. |
Third-party certification | BBA Certified 21/5944 Product Sheet 4 (Pending). |
Fire performance | To EN 13501-1, Euroclass E. |
Compressive strength (minimum) at 10% compression | 300 kPa. |
Thermal conductivity (maximum) | Declared: 0.034 W/m·K. |
Water permeability | Total immersion: ≤0.7%; Diffusion: Class WD(V) ≤3. |
Water vapour permeability | 160 μ. |
Thickness | 40 mm. |
Face size (length x width) | 1250 x 600 mm. Guidance for specification option: Coverage: 0.75 m². |
Edges | Shiplap. |
U-value | 0.73 W/m²K. |
Thermal resistance | 1.15 m²K/W. |
Sustainability data
Material | Extruded polystyrene (XPS) |
