AS35 Composite Roof Panel
Verified by manufacturer 17 days ago
40 mm-thick
40 mm-thick
PIR insulated, self-supporting composite panel for roofing.
Application
For roofing applications. AS35 panels are designed to be fixed to steel purlins and side rails using appropriate self-drilling fasteners. They are suitable for a variety of applications, including:
- Retail parks.
- Office buildings.
- Schools.
- Sports centres.
- Commercial units.
Description
A self-supporting composite panel suitable for roofing.
Features and benefits:
- Insulated panel.
- Available in an extensive range of colours.
- Plastisol external coating
- Can be fully integrated with both modern and traditional methods of construction.
- Polyisocyanurate (PIR) core.
- CE marked to BS EN 14509:2013 self-supporting double skin metal faced insulating panels.
General information
Color | Other Black Blue Brown Green |
Finish | Plastisol Coated |
Material | Steel Polyisocyanurate (PIR) Composite |
Shape | Rectangle Trapezoid |
Length | Bespoke Guidance for specification option: Standard lengths 1800–14000 mm. 12000 mm 2000 mm |
Width | 1000 mm Manufacturer guidanceCover width. |
Height | 40 mm 60 mm 70 mm 80 mm 100 mm Manufacturer guidancePanel thickness. |
Warranty description | 25 year Guidance for specification option: System guarantee. |
Uniclass | |
CAWS | H43/10 Metal insulating sandwich panel H43/120 Metal insulating sandwich panel |
Specification data - Carbon steel insulating sandwich panels
Standard | To BS EN 14509. |
Panels | Factory-assembled insulating sandwich panels. |
Panel construction | |
Panel external face | |
Material | Steel. |
Profile | Manufacturer guidanceConsult manufacturer for details. |
Thickness | 0.5 mm. |
Panel internal face | |
Material | Steel. |
Profile | Manufacturer guidanceConsult manufacturer for details. |
Thickness | 0.4 mm. |
Core insulation | Rigid polyisocyanurate foam (PIR). |
Panel dimensions | |
Length | Guidance for specification option: Insert requirements.
|
Cover width | 1000 mm. |
Thickness | 40 mm. |
Joint type | |
Side or vertical | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
End or horizontal | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
Curvature | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Taper | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Finish as delivered | |
Outer skin | |
Material | Plastisol PVC (P). |
Thickness | Manufacturer guidanceConsult manufacturer for details. |
Colour | Manufacturer guidanceExtensive colour range. Consult manufacturer and insert requirements. |
Inner skin | |
Material | Polyester. |
Thickness | Manufacturer guidanceConsult manufacturer for details. |
Colour | White. |
Integral accessories | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Special features | Self-supporting and capable of spanning supports at 1.5–3.0 m centres. |
Fire performance | |
Reaction to fire | |
Core | To BS EN 13501-1: B-s2,d0. |
Panel external face | To BS EN 13501-5: Broof(t4). |
Panel internal face | To BS EN 13501-1: B-s2,d0. |
Fire resistance | Manufacturer guidanceConsult manufacturer for details. |
Fire performance | Guidance for specification option:
Manufacturer guidanceFire Performance to LPS 1181:2005. |
U-value | 0.50 W/m²K. |
Span | Single span. Double span. Manufacturer guidanceConsult manufacturer's literature for details. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Steel Polyisocyanurate (PIR) Composite |
Literature
AS35 Composite Roof Panel
