Aluprof MB-86 - Door System

Name: Aluprof MB-86 - Door System
Brand: Aluprof UK
SKU: r9eLUnw63VUjUumobF5jm4

Verified by manufacturer 9 months ago

Aluprof MB-86 ST - standard framed system

Aluprof UK

Third party certifications:

Cradle to Cradle Certified
Certificate type
EPD
Certificate type
EMS ISO 14001
Certificate type
QMS ISO 9001
Certificate type
BM Trada
Certificate type
Qualicoat approval
Certificate type
Secured By Design
Certificate type

High performance, thermally broken aluminium swing door system with four thermal variations offer the best thermal performance to meet the latest standards and regulations.

Jump to:

+44 (0)161 9414005 Website

Application

Suitable for all project sectors: Commercial, education, healthcare, hospitality, offices, residential, retail and many more.

Description

The MB-86 door series have been designed to offer outstanding insulation properties.

Offered in three thermal varieties, 'ST', 'SI' and 'AERO'. With the high performing AERO version offering exceptionally low values of thermal conductivity.

In addition, a high level of profile inertia capability allows for greater construction sizes and weights.

Features and benefits:

Large selection of profiles available.
A maximum width of 1400mm and a maximum height of 3000mm per leaf.
Glazing thickness up to 61.5 mm: to enable the use of double and triple glazed options for thermal, acoustic and security solutions.
Centre gasket for improved thermal and weather tightness.
Appropriate for a variety of visible or concealed hardware available in steel, anodised and powder coated finishes.
Highly energy efficient U'value performance.
Clean, sharp lines of narrow extruded aluminium framing.
Various finishes available including powder coating and anodising in a wide range of colours.

Performance:

Air permeability to EN 12207:2001: Class 4.
Wind load resistance to EN 12210:2001: Class C1/B2.
Watertightness to EN 12208:2001: Class E1350.
Thermal insulation performance to meet the latest Part L requirements
PAS 24 and Secured by Design certification available

General information

Finish	Anodized Powder-coated Polyester powder-coated.
Material	Aluminium
Shape	Square Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
WarrantyDescription	25 year Up to 25 years for polyester powder-coated finishes. Ten year Up to ten years for anodized finishes.

Uniclass	Pr_30_59_24_02 Aluminium doorsetsPrimary
CAWS	L20/480 Doorsets L20/55 Doorsets

Specification data - Aluminium doorsets

Standard Consult manufacturer for details.	Non-fire and/ or smoke rated windows to EN 14351-1 and BS 4873.
Third party accreditation	CE marked; Q-Mark; ITB - EPD Certification; Qualicoat/ Qualanod/ Qualideco; Secured by Design. Qualicoat/ Qualanod/ Qualideco dependent on finish specified.
Configuration Consult manufacturer and insert requirements.	Single, open in. Single, open out. Double, open in. Double, open out.
Doorset size Add dimensions and/ or drawing references as required. Maximum (door leaf, h x w): 3000 x 1400 mm. Maximum weight: 200 kg.	-
Performance	-
Acoustic performance Insert requirements; dependent on variant specified: Up to 42 (-1,-4) dB Rw.	-
Strength and durability	Not required. Class 1. Class 2. Class 3.
Thermal Consult manufacturer and insert requirements.	-
Intruder resistance	-
Minimum requirement	Secured by Design. To PAS 24.
Application	Manufacturer's standard.
Conformity	Secured by Design.
Frame	-
Material	Aluminium.
Threshold	Standard rebated frame. Low level threshold. Low level ramped threshold. Low level thermal performance threshold. Automatic drop down threshold.
Perimeter seals or inserts	Ethylene propylene diene monomer (EPDM) weather seal. External mastic seal. Internal mastic seal.
Finish	-
Coating	Anodized by Aluprof to Qualanod standard, 25 µm film thickness. Polyester powder-coated by Aluprof to Qualicoat standard, 60 µm film thickness. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, 60 µm film thickness. Polyester powder-coated by Aluprof to Qualideco standard, 60 µm film thickness. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, 60 µm film thickness. Bespoke. Insert details of external and internal and coatings choices from the list above. Colours specified separately below.
Texture	Dependent on coating specified.
Colour	RAL, Matt. Polyester powder-coated coatings only; insert colour requirements. RAL, Satin Gloss. Polyester powder-coated coatings only; insert colour requirements. RAL, High Gloss. Polyester powder-coated coatings only; insert colour requirements. RAL, Structure. Polyester powder-coated coatings only; insert colour requirements. RAL, imitation anodized. Polyester powder-coated coatings only; insert colour requirements. NCS. Polyester powder-coated coatings only; insert colour requirements. Special effects. Polyester powder-coated coatings only; includes fine and coarse structure, metallic effect or diverse gloss. Consult manufacturer for details and insert requirements. Decoral (wood grain effect). Polyester powder-coated coatings only; insert colour requirements. Natural silver. Anodized only. Coloured anodized to Aluprof 'C' range. Anodized only; insert colour requirements.
Installation fasteners	Manufacturer's standard.
Door leaf	-
Thickness	Manufacturer's standard.
Core	Manufacturer's standard.
Material	Aluminium.
Perimeter seals Consult manufacturer and insert requirements.	-
Glazing	-
Type Thickness of 13.5–61.5 mm available; insert requirements.	-
Manifestation Consult manufacturer and insert requirements.	-
Beading	-
Type Consult manufacturer and insert requirements.	-
Material	Aluminium.
Fixing	Manufacturer's standard.
Finish	-
Coating Consult manufacturer and insert requirements.	Anodized by Aluprof to Qualanod standard, 25 µm film thickness. Polyester powder-coated by Aluprof to Qualicoat standard, 60 µm film thickness. Polyester powder-coated by Aluprof to Qualicoat 'seaside' standard, 60 µm film thickness. Polyester powder-coated by Aluprof to Qualideco standard, 60 µm film thickness. Polyester powder-coated by Aluprof to Qualideco 'seaside' standard, 60 µm film thickness. Bespoke. Insert details of external and internal and coatings choices from the list above. Colours specified separately below.
Texture	Dependent on coating specified.
External colour Consult manufacturer and insert requirements.	RAL, Matt. Polyester powder-coated coatings only; insert colour requirements. RAL, Satin Gloss. Polyester powder-coated coatings only; insert colour requirements. RAL, High Gloss. Polyester powder-coated coatings only; insert colour requirements. RAL, Structure. Polyester powder-coated coatings only; insert colour requirements. RAL, imitation anodized. Polyester powder-coated coatings only; insert colour requirements. NCS. Polyester powder-coated coatings only; insert colour requirements. Special effects. Polyester powder-coated coatings only; includes fine and coarse structure, metallic effect or diverse gloss. Consult manufacturer for details and insert requirements. Decoral (wood grain effect). Polyester powder-coated coatings only; insert colour requirements. Natural silver. Anodized only. Coloured anodized to Aluprof 'C' range. Anodized only; insert colour requirements. Brushed silver anodized. Heavy brushed silver anodized.
Internal colour Consult manufacturer and insert requirements.	RAL, Matt. Polyester powder-coated coatings only; insert colour requirements. RAL, Satin Gloss. Polyester powder-coated coatings only; insert colour requirements. RAL, High Gloss. Polyester powder-coated coatings only; insert colour requirements. RAL, Structure. Polyester powder-coated coatings only; insert colour requirements. RAL, imitation anodized. Polyester powder-coated coatings only; insert colour requirements. NCS. Polyester powder-coated coatings only; insert colour requirements. Special effects. Polyester powder-coated coatings only; includes fine and coarse structure, metallic effect or diverse gloss. Consult manufacturer for details and insert requirements. Decoral (wood grain effect). Polyester powder-coated coatings only; insert colour requirements. Natural silver. Anodized only. Coloured anodized to Aluprof 'C' range. Anodized only; insert colour requirements. Brushed silver anodized. Heavy brushed silver anodized. As External colour.
Film thickness (minimum)	60 µm (PPC) or 25 µm (Anodized). Dependent on coating specified.
Door accessories Consult manufacturer and insert requirements.	-
Hardware	Standard, silver. Standard, white. Standard, brown. Standard, silver anodized. Standard, RAL colour to match frame. Specify if interior and exterior values differ. Enhanced Security (PAS 24), silver. Enhanced Security (PAS 24), white. Enhanced Security (PAS 24), brown. Enhanced Security (PAS 24), silver anodized. Enhanced Security (PAS 24), RAL colour to match frame. Specify if interior and exterior values differ. Enhanced Security (RC2), silver. Enhanced Security (RC2), white. Enhanced Security (RC2), brown. Enhanced Security (RC2), silver anodized. Enhanced Security (RC2), RAL colour to match frame. Specify if interior and exterior values differ. Enhanced Security (RC3), silver. Enhanced Security (RC3), white. Enhanced Security (RC3), brown. Enhanced Security (RC3), silver anodized. Enhanced Security (RC3), RAL colour to match frame. Specify if interior and exterior values differ. Enhanced Security (RC4), silver. Enhanced Security (RC4), white. Enhanced Security (RC4), brown. Enhanced Security (RC4), silver anodized. Enhanced Security (RC4), RAL colour to match frame. Specify if interior and exterior values differ.
Architraves	-
Material	Manufacturer's standard.
Finish Consult manufacturer and insert requirements.	-
Colour Consult manufacturer and insert requirements.	-
Accessories Consult manufacturer and insert requirements.	-

Ironmongery	Single point locking. Consult manufacturer and insert requirements. Multipoint locking. Emergency exit (EN 179). Panic Escape (EN 1125). Electric strike single point locking. Electronic multipoint locking. Show more
Installation	The MB-86 door system specified above shall be fabricated and installed by Aluprof approved companies only, in complete accordance with the information and guidance distributed by Aluprof UK Ltd.
