Brise soleil cassette system for effective protection against year-round sun and hot summer temperatures.
Aluminium brise soleil blades pitched at 62 degrees to take the 'sting' out of summer sun on occupied buildings.
Skyvane® Aerofoil Brise Soleil is composed of aluminium blades that can be angled for bespoke design or specific shading requirements. Fixings and supports ensure seamless alignment for both aesthetic and practical results.
Panel Construction Cassette:
System Construction Solo:
Bracket Construction:
a) Laser-cut and folded brackets, designed and engineered to suit the project location, wind loadings, and tolerances. Manufactured from mild steel S275 (or similar), and fixed directly to suitable fixing grounds.
b) TRINITI curtain walling bracket, manufactured from Aluminium 6063 T6.
Blade Colour/Finish: Specific to each project – polyester powder-coated 60 µm or anodized 25 µm.
Bracket Colour/Finish: Specific to each project – hot dip galvanized or polyester powder-coated 60 µm. Mill finish.
Color | Other Guidance for specification option: All aluminium polyester powder coated to RAL / BS colour from standard range. Beige Black Blue Bronze |
Finish | Powder-coated Anodized |
Material | Aluminium Guidance for specification option: Grade 6063 T6 Extruded aluminium. |
Shape | Rectangle Square |
Length | Bespoke Manufacturer guidanceVarious sizes available, contact manufacturer. |
Width | Bespoke Manufacturer guidanceVarious sizes available, contact manufacturer. |
Height | Bespoke Manufacturer guidanceVarious sizes available, contact manufacturer. |
Warranty description | Three year Guidance for specification option: Dependent on specified finish and project location, consult manufacturer. |
Uniclass | |
CAWS | L10/670 Brises-soleil L10/55 Brises-soleil |
Support arms | |
Material | Grade 6063 T6 extruded aluminium.Aluminium 5083 H111 T6. |
Finish | Polyester powder-coated.Guidance for specification option: 60 μm coating. Anodized.Guidance for specification option: 25 μm coating |
Brace arms | |
Material | Not required.Aluminium. |
Rod diameter | Not required.32 mm.Guidance for specification option: Used in larger projections. Manufacturer guidanceBrace arms rod diameter |
Array louvre blades | |
Profile | Aerofoil.Eliptical. |
Size | 100 x 50 mm. |
Pitch | 62°.Guidance for specification option: To protect against high summer sun. |
Finish | Polyester powder-coated.Guidance for specification option: 60 μm coating. Anodized.Guidance for specification option: 25 μm coating |
Type | Cassette. Standard. |
Brackets | Galvanized mild steel (S275 or similar). TRINITI curtain wall bracket (Aluminium 6063 T6). |
Fixing | A2 stainless steel with bi-metallic corrosion resistance. |
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Material | Aluminium Guidance for specification option: Grade 6063 T6 Extruded aluminium. |
Recyclability | 95% |
Expected Life | 80 year |
