AFD Indigo Calcium Sulphate Range - Raised Access Floor System

Name: AFD Indigo Calcium Sulphate Range - Raised Access Floor System
Brand: Access Floors Distribution
SKU: wFCW5DUjiFdmCkrd8ewxsh

Verified by manufacturer 1 day ago

Class 3 BSEN

Access Floors Distribution

Indigo CS raised access floors with calcium sulphate core panels. Non-combustible, moisture resistant, and acoustically superior for demanding environments.

Jump to:

BOS

01480 367096 Website

Application

The Indigo CS Range is suited for technical and specialist environments where safety, durability, and environmental performance are critical. Its combination of fire resistance, acoustic performance, and moisture resistance makes it particularly effective in:

Data Centres & IT Suites – supports high equipment loads while offering anti-static protection and full accessibility for service integration.
Communication Rooms & Equipment Rooms – provides a robust platform for sensitive equipment, ensuring stability and safety.
Manufacturing Facilities – resistant to moisture and impact, suitable for industrial and technical production environments.
Recording Studios & Acoustic Spaces – offers superior airborne and impact sound insulation to meet demanding acoustic requirements.

The system’s calcium sulphate core delivers long-term stability and durability, while the wide void and finish options ensure flexibility across a range of building types. Its sustainable composition (94% recycled content) also makes it an appropriate choice for projects targeting BREEAM, LEED, or other green building certifications.

Description

The Indigo CS Range is a specialist raised access floor system featuring robust calcium sulphate (gypsum fibre) core panels. It is designed for projects where enhanced fire resistance, acoustic control, and moisture resistance are essential.

With thickness options between 30–38 mm, Indigo CS panels surpass conventional wood core alternatives, offering outstanding load-bearing capacity, fire performance, acoustic behaviour, and humidity resistance.

Each panel is manufactured with an ABS edge band trim and is available in a wide selection of factory-bonded finishes, including:

Anti-static vinyl
High pressure laminate (HPL)
Rubber
And more project-specific options

Features & Benefits

Fully accessible raised floor system.
High load capability with a lightweight design.
Extended fire resistance with a non-combustible calcium sulphate core.
Superior acoustic performance for noise-sensitive environments.
Excellent resistance to humidity compared with wood core panels.
Choice of durable bonded finishes for technical or aesthetic needs.
Manufactured using 94% recycled material, supporting sustainability goals.
Anti-static and conductive performance options for sensitive equipment areas.

Indigo CS represents a future-proof solution for architects, designers, and specifiers seeking reliable, durable, and sustainable raised access flooring for specialist environments.

General information

Color	White
Material	Calcium sulphate Rubber Vinyl High pressure laminate (HPL)
Shape	Square
Length	600 mm
Width	600 mm
Height	30 mm 34 mm 36 mm 38 mm
Warranty description	25 year

Uniclass	Ss_30_20_70_37 Hollow floor systemsPrimary Ss_30_20_70_70 Raised access floor systems
CAWS	K41/130 Raised access floor K41/130 Proprietary raised access floor

Specification data - Hollow floor systems

Classification data
System performance	Class 1–6+, to BS EN 12825:2001.
System reference	AFD Indigo Calcium Sulphate Range - Raised Access Floor System.
Standards	To BS EN 13213, BS EN 12825.
Products	AFD CS 30.5 mm.
Subfloor Preparation layer	Prepare the subfloor by ensuring the area is clean, swept and clear. Prepare the sub floor by applying two layers of PVA sub floor sealer.
Structure	M16 pedestal voids 50–250 mm. M20 pedestal voids >250 mm.
Pedestal	Adhered to the subfloor using AFD 1-Part Pedestal Adhesive. Guidance for specification option: Consider mechanical fixing for voids over 600 mm (two fixings per pedestal).
Floor surface	AFD CS 30.5 mm.
System accessories	None. Bare base. Guidance for specification option: Optional, aluminum foil or galvanized steel. Insert requirements. Stringer for higher voids >600 mm. Pedestal cap.
Surface finish	Anti-static vinyl. High pressure laminate. Rubber.
Fire classification	To EN 13501-1, A2.
Fire resistance	To EN 13501-2, REI 30.
Load class	To BS EN 13213, class 3.
Deflection	Class A.
Load	Ultimate point load: 8 kN. Working point load: 4 kN.
Safety	2.
Weight	55 kg/m². Guidance for specification option: Nominal. Manufacturer guidance System weight.
Sound	Airbourne sound (Dnfw): 50 dB. Impact sound (Lnfw): 69 dB.

Sustainability data

Contains Red List materials	No
Country of material origin	Germany
Country of product manufacture	Europe
Material	Calcium sulphate Rubber Vinyl High pressure laminate (HPL)
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	94 %
Expected Life	25 year
