60 cm Venting Hobs with Integrated Extraction Unit
Verified by manufacturer 28 days ago
Induction hob with integrated ventilation system.
Application
For domestic applications.
Description
Induction hob with integrated ventilation system surface mounted without a frame.
Features and benefits:
- combiZone enables the user to cook with large pots and roasting pans.
- touchControl makes the control of the cooktop convenient, just by the touch of a finger.
- The inductionAir Plus guarantees minimal noise without compromising on suction power.
- Easy cleaning – minimal cleaning effort for the built-in extractor.
- powerBoost – increases the power of an induction zone by up to 50%.
Models:
- ED611BS16E: 60 cm inductionAir venting hob, touchControl, 4 x zones, one combiZone and ventilation, auto-on fan, 7.4 kW, frameless, includes four cleanAir Plus filters, a telescopic slider, and an adhesive seal for un-ducted installation.
General information
Color | Black |
Material | Ceramic Glass |
Shape | Rectangle |
Length | 522 mm |
Width | 592 mm |
Height | 223 mm |
Warranty description | Two year |
Uniclass | |
CAWS | N12/330 Cooking equipment N12/330 Cooking equipment N11/360 Appliances N11/40 Appliances |
Specification data - Built-in electric hobs
Hob arrangement | Ceramic hob with two 3.7 kW combi zones.Guidance for specification option: combiZone: use bigger cookware by connecting two classic cooking zones into one large zone.
|
Dimensions | |
Width (maximum) | 592 mm. |
Depth (maximum) | 522 mm. |
Rating | 7.4 kW. |
Electrical supply | 220–240 V.380–415 V. |
Material and finish | Ceramic black. |
Features | Automatic safety cut-out. |
Frequency | 50-60 Hz. |
Cable length | 110 cm. Manufacturer guidanceLength electrical supply cord. |
Output | Maximum output air extraction: 500 m³/h. |
Noise | 69 dB (A) re 1 pW. Manufacturer guidanceNoise level. |
Energy rating | B. |
Mounting | Worktop mounted. |
Control | TouchControl. |
Heating element | Power of second heating element: 3.6 kW. |
Integral accessories | Slider for unducted recirculation, clean air plus odor filter. |
Accessories | Not required. HZ9VRPD1: Plinth diffusor. HZ9VRCR1: Clean air plus odor filter (replacement). HZ9VRCR0: cleanAir recirculation replenishment fil. HZ9VEDU0: Acoustics filter. |
Sustainability data
Material | Ceramic Glass |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
iQ300, Induction hob with integrated ventilation system, 60 cm, surface mount without frame ED611BS16E
