4 Hour Compact Fire Resisting Roller Shutter - Fireguard FT04

Name: 4 Hour Compact Fire Resisting Roller Shutter - Fireguard FT04
Brand: HAG Ltd. - The Door Specialists
SKU: jREz2adNhC1uaCqWkTeUnB

Verified by manufacturer 9 days ago

HAG Ltd. - The Door Specialists

Third party certifications:

ADSA
Certificate type
Alcumus SafeContractor
Certificate type
CHAS
Certificate type
Constructionline
Certificate type
dhf certificate
Certificate type
Warringtonfire
Certificate type
ISO 9001 Quality Management
Certificate type
DoP
Certificate type
AkzoNobel
Certificate type
UK Conformity Assessed (UKCA)
Certificate type
FIRAS
Certificate type

Fire shutter with Fire Integrity (E) of 240 minutes, FIRAS installation certified, and compliant with BS EN 16034 fire regulations. Suitable for both commercial and domestic applications.

Jump to:

BOS

0800 072 3444 Website

Application

Fire Shutter suitable for industrial, commercial, residential, public buildings, hospitality and cultural or historical settings

Airports
Train stations
Kitchen servery hatches
Retail units
Shopping malls
Offices
Leisure complex
Warehouse
Factories
Chemical plant
Hospitals
Care homes
Receptions areas
Schools
Colleges
Academies
Universities
Nurseries
Residential - high rise or large houses
Hotels
Restaurants
Museums
Libraries
Historical sites

Description

High-security compact tubular-driven fire shutter offering 240 minutes of fire protection.

Features and benefits:

Recommended maximum width up to 7000 mm.
Tested to BS EN 1634-1 and compliant with BS EN 16034:2014.
Galvanized steel finish with powder coating available at additional cost.
Constructed from steel sections of 76 mm cold rolled 20 gauge galvanized steel.
Offers the ability to be installed in areas where traditional fire shutters are not possible.
Provides a defence against the spread of fire and can be used as a security door on a day to day basis.
Can be linked to audio/ visual deacon fire alarms to ensure automatic closing in case of fire detection with battery backup in the event of power failure.
Also available in 60 and 120 minutes fire resistance models (specified separately).

FIRAS INSTALLER CERTIFICATION SCHEME

HAG Is accredited to install fire protection products by Warrington fire through its FIRAS installation certificate scheme.

FIRAS is the mark of endorsement of competency in the installation of products and systems, vital for achieving the protection required and is accredited by UKAS to BS EN ISO/IEC 17065:2012.

Insurances could be invalid if proof of a competent product installer is not verified.

General information

Color	Silver Guidance for specification option: Standard. Other Guidance for specification option: Polyester powder-coating.
Finish	Galvanized Guidance for specification option: Standard. Powder-coated Guidance for specification option: Polyester powder-coated (PPC).
Material	Steel
Shape	Rectangle
Length	Bespoke
Width	7000 mm Manufacturer guidance Maximum width.
Height	Bespoke
Warranty description	One year

Uniclass	Pr_30_59_84_30 Fire-resisting roller shuttersPrimary
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	Fire Protection

Specification data - Fire-resisting roller shutters

Standard	To BS EN 1634-1 and compliant to BS EN 16034:2014.
Opening sizes	- Manufacturer guidance Insert requirements, maximum width of 7000 mm. Box sizes: Overall height (top of box): Up to 2000 mm, box size: 250 mm. Up to 3000 mm, box size :300 mm. Up to 4000 mm ,box size: 350 mm. On larger widths the box sizes may move up one size due to deflection.
Arrangement	Vertical rolling, automatic.
Performance	-
Fire performance	-
Fire resistance	Integrity (E) 240 minutes.
Frame and guides	-
Material	Galvanized steel. Guidance for specification option: Guide rail: 50–76 x 32 x 3 mm, dependent on width and height.
Finish	Galvanized. Guidance for specification option: Standard. Polyester powder-coated.
Colour	Galvanized. Guidance for specification option: Standard. Manufacturer guidance For special order, consult manufacturer for details.
Frame accessories	None. Shutter box design. Guidance for specification option: 1.5 mm bright spangle galvanized pressed steel coil casing available in various different designs to suit individual circumstances.
Shutter curtain	-
Lath material	Galvanized steel.
Profile	Flat. Guidance for specification option: 76 mm.
Finish and colour	Galvanized. Guidance for specification option: Standard. Polyester powder-coated, colour. Guidance for specification option: Consult manufacturer and insert requirements.

Weight	12.5 kg/m². Guidance for specification option: Dependent on size.
Operation	Electrical, single phase. Guidance for specification option: Tubular motor within the barrel assembly with limit switches and thermal cut out. Provision of a 13 A fused spur is required for installation.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Steel
Recyclability	yes Manufacturer guidance 95%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	17 %
