3230 Classic - Carpet
Application

suited for heavy footfall public buildings.

Description

A heavy contract, fibre-bonded sheet carpet in a classic flat design.

Features and benefits:

  • Achieves either A or A+ across all the BREEAM-defined building applications.
  • Constructed from a combination of polypropylene and nylon solution-dyed fibres.
  • A+ VOC rating, on very low emissions of volatile substances in indoor air.

Application:

suited for heavy footfall public buildings.

General information

Material

Pile Fibre: 85% Polypropelene 15% Nylon

Shape

Rectangular

Size

4.8 x 2000 x 30000 mm

Uniclass 2015

Pr_35_57_11_30 Flat needled carpetsPrimary

CAWS

M50/170 Carpeting

M50/25 Carpeting

Specification data - Flat needled carpets Enhanced data

Product Reference

3230 classic

Standard

Heavy contract

Classification

-

Level of use class

Heavy contract

Width

2000 mm

Colour and pattern

2101 cornwall blue

2102 devon blue

2104 hampshire slate

2105 sussex sea

2106 kent mauve

2107 surrey blue

2109 glamorgan grey

2110 berkshire black

2111 wiltshire charcoal

2112 suffolk heather

2114 shropshire maroon

2115 norfolk sun

2117 cheshire jade

2118 yorkshire fern

2119 lancashire green

2126 grampian gold

2128 angus tan

2129 falkirk fawn

Weight

915 g/m²

Thickness

4.8 mm

Length

30 m

Flammability

Euroclass Cfl-s1

Durability

-

Castor chair rating (to BS EN 985)

Pass – suitable for continuous use

Static loading (to BS 4939:1987 (2003))

Recovery >80% (24 hours)

Dynamic loading (to BS ISO 2094:1999 (2005))

Loss <20% (1000 impacts)

Static electricity

Body voltage test (to BS ISO 6356:2000): <2 kV

Sound performance

Reduction in impact noise (to BS EN 140-8:1998): 17 dB

Colour fastness

Light (to BS EN ISO 105 – BO2): grade 6 (minimum); shampoo (to BS 1006: UK-TB:1990): grade 4 (minimum)

Thermal resistance

Tog rating 0.89; ISO 8302: 0.09 m²K/W

Environmental specifics

EPD-assessed

Dynamic loading

Loss <20%

Reduction in impact

-

Noise

17 dB

Noise at 1000 Hz

16.4 dB

Standard product features

Colour:

Wide range available.

Features:

Classic, flat design.

Material:

Fibre-bonded sheet carpet. Pile fibre: 85% polypropylene, 15% nylon.

Shape:

Rectangular.

Size:

4.8 x 2000 x 30 000 mm.

Warranty description:

Ten-year warranty.

Embodied carbon:

3.54 kg/ 1 m².

Country of origin:

United Kingdom.

Environmental information

Embodied carbon

3.54 kg/ 1 m²

Digital objects
PlatformCompatibleVersionCertified to
IFC
- 3 1.3
Revit
Revit 2016 4 2.0
Download now from NBS National BIM Library
Literature
Third party certifications
  • BS EN 1307
