EasyGate LC / Lift Call

Verified by manufacturer over a year ago

Centaman Entrance Control

Swing barrier speedgate with options for building in 3rd party hardware.

Jump to:
+61 2 9906 7522 Website

Application

Most suitable for corporate offices.

Description

The Centurion EasyGate LiftCall is a designed orientated swing barrier speedgate intended to ensure only one person gains access for each authorised card presented. The EasyGate uses glass barriers that swing away from authorised user in a friendly door like motion in conjunction with optical tailgate detection technology to provide a high throughput / high security gate.


The EasyGate LiftCall is designed to be integrated with destination lift control system. The pedestal is designed to be as narrow as possible but wide enough to fit a 3rd party destination lift control display.

General information

Warranty description

Two year

Uniclass

Pr_30_59_34_34 Glazed half-height turnstilesPrimary

NATSPEC National Classification System

0451a Windows and Glazed Doors – Metal

0451 Windows and Glazed Doors

SpecPack

08200 Doors, Door Frames and Hatches

Specification data - Glazed half-height turnstiles

Leaves

-

Type

Toughened Clear Safety Glass.

Manufacturer guidance

Options for adding custom logos on glass barriers and/or colour LED indicators.

Thickness

8 mm.

Surrounds

-

Type

Sheet metal.

Material

Stainless steel (304 Brushed).

Rotation

Card In / Card Out

Card In / Free Exit

Operation

Electrical.

Dimensions

-

Overall depth

1400 mm.

Overall height

990 - 1800 mm.

Passage width

550 mm

650 mm

750 mm

900 mm

920 mm

1000 mm

Manufacturer guidance

Customisable

Control units

-

Device acceptance

Card reader.

Biometric controls.

Coin acceptance units.

Intercom.

Proximity detection devices.

Remote controls.

Operational voltage

Power supply: 230 Volts. Control Electronics: 12 Volts DC.

Finish

-

Worked finish

Brushed.

Finish:

Top Cover: 8 mm Smoked Glass. Front Cover: Smoked glass.

Manufacturer guidance

Other options available

Accessible design

DDA compliant.

Manufacturer guidance

DDA compliance only applies when gates are at the correct spacing.

Security

Fast-acting barriers close behind authorised users to deter tailgating.

Sensors

Up to 30 sensor pairs.

Opening speed

0.7 Seconds.

LED pictograms

Wait Mode (White Indicator).
Access Granted (Green Indicator).
Illegal Transaction (Red Indicator).

MeanTimeBetweenFailure

3,000,000 operations.

Operation:

Normally Closed.

BIM objects

Platform Compatible Version
Revit
-

1

Literature

Easygate LC- Technical Specification

Easygate LC- Technical Specification

EasyGate Lift call - Brochure

EasyGate Lift call - Brochure
