X-Grid® is a high-strength, lightweight, and fully permeable ground reinforcement and gravel retention system manufactured in the UK from 100% recycled plastic.

With a load capacity of up to 428 tonnes per m² and a weight of just over 5 kg per m² (0.57 kg per panel), X-Grid® provides a durable, low-maintenance, and sustainable solution for ground stabilization.

The open-cell structure can be filled with a wide range of materials, including gravel, grass, and soil blends, ensuring a finish suitable for practically any project. X-Grid® is widely used for eco-friendly access roads, driveways, car parks, pathways, cycle routes, event flooring, equestrian areas, golf courses, and landscaping projects.

By offering an environmentally conscious alternative to traditional ground reinforcement products such as concrete, asphalt, or tarmac, X-Grid® combines performance with sustainability. Its permeable design allows rainwater to naturally infiltrate through the surface, reducing localised flooding, managing surface water run-off, and supporting compliance with SuDS (Sustainable Drainage Systems).

KEY FEATURES AND BENEFITS

X-Grid® combines lightweight design, high strength, and full permeability in one system, making it one of the most effective ground stabilisation products available. Manufactured from 100% recycled plastic, it offers a reliable alternative to concrete or asphalt while remaining simple to handle, install, and maintain.

Made from 100% Recycled Plastic: Produced in the UK from recycled plastic waste, reducing landfill and supporting circular economy goals. Fully recyclable at end of life.
Lightweight and Easy to Handle Panels: Each panel weighs just 0.57 kg (5.13 kg per m²), making them easy to carry and install without heavy machinery.
Ultra-Strong Load Capacity: Capable of withstanding over 420 tonnes per m² before being filled, suitable for cars, HGVs, and fire access routes.
Fully Permeable Structure: Open cell design allows water to drain naturally, helping prevent surface water build-up and supporting SuDS compliance.
Weather and Chemical Resistant: Withstands frost, UV exposure, and chemicals, ensuring long-term performance without cracking or becoming brittle.
Versatile Applications: Ideal for driveways, car parks, access roads, footpaths, cycleways, campsites, festival grounds, equestrian areas, golf courses, and landscaping projects.
Accessible and Inclusive: Provides a stable surface for both gravel and grass finishes, meeting requirements for wheelchair and pedestrian access.
Secure Interlocking System: Tight-fitting, integral slot-and-peg connectors lock panels together, forming a seamless, stable surface without extra fixings.
Low Maintenance: Once filled with gravel or grass, the surface remains durable and stable with minimal upkeep, reducing lifetime costs compared to traditional surfacing.

ENVIRONMENTAL BENEFITS

X-Grid® contributes to sustainable construction by offering a recycled, recyclable, and permeable ground reinforcement solution. By reducing reliance on traditional impermeable surfaces such as concrete and asphalt, it lowers environmental impact while supporting SuDS requirements. The system helps prevent flooding, encourages biodiversity, and reduces surface water management costs.

Made from 100% Recycled Plastic, preventing plastic waste from going to landfill.
Supports SuDS-compliant Drainage by enabling natural water infiltration.
Effectively Replaces Impermeable Materials like asphalt, resin-bonded surfaces, and concrete.
Encourages Greener Infrastructure and Biodiversity through grass-fill options.
Fully Recyclable at End of Life, supporting a circular and sustainable construction approach.
Helps Mitigate Flood Risks by managing surface water runoff efficiently, minimizing potential water damage, and reducing strain on local drainage systems.

PERFORMANCE & TECHNICAL DATA

Engineered for durability, X-Grid® delivers strength, sustainability, and ease of installation in a lightweight ground reinforcement solution. Manufactured in the UK from 100% recycled HDPE, each panel measures 330 x 330 x 40 mm and weighs just 0.57 kg, allowing a single person to install up to 100 m² per hour without machinery.

The modular design means nine panels form a nominal square metre, enabling flexible layouts with minimal product wastage. Independently tested to ultimate failure by Lloyds British Testing under ISO 9001:2008 quality standards, X-Grid® has demonstrated a load capacity of up to 428 tonnes per m².

With a life expectancy of 25 years and a 10-year manufacturing defect warranty, X-Grid® provides proven long-term performance for driveways, access roads, car parks, pathways, and landscaping projects.

Load Bearing Capacity: Up to 428 tonnes per m² unfilled
Panel Size: 330 x 330 x 40 mm
Weight per Panel: 0.57 kg
Material: 100% recycled UK Sourced HDPE (high-density polyethylene)
Temperature Resistance: -50 to +90°C
UV & Weather Resistance: Yes
Chemical Resistance: Resistant to oils, acids, and salts
Connection Type: Integral slot & peg connection
Finish Options: Gravel-filled, soil and grass-filled, or mulch/bark
Permeability: 97% porous surface for effective water infiltration
Life Expectancy: 25 years (10 year manufacturing defect warranty)

APPEARANCE:

Available in three colours, X-Grid® offers a variety of options to cater to your project's unique aesthetic needs and environmental considerations. Each colour provides a distinct look and functionality, ensuring a suitable solution for different preferences and contexts.

Black X-Grid: The original X-Grid® is one of the most cost-effective ground reinforcement grid available. With over 9 million units sold worldwide, this is our most popular grid.
Green X-Grid: Perfect for reinforced grass surfaces, X-Grid® green is manufactured with creating grass access routes in mind. Ideal for use on heritage lands and areas of outstanding natural beauty.
Natural X-Grid: Perfect for pale coloured gravels, X-Grid® Natural is one of the only white permeable gravel grids available on the market. Helps to disguise the grid on installations where aesthetics are key.

COMPLIANCE AND STANDARDS

X-Grid® is designed to meet the needs of modern construction projects by supporting SuDS compliance, sustainable design targets, and emergency access standards. Manufactured in the UK under strict quality control, it provides assurance for architects, contractors, and specifiers working on residential, commercial, or public sector schemes.

Compliant with Sustainable Drainage Systems (SuDS) and surface water management best practices.
Suitable for projects working towards BREEAM and LEED credits.
Manufactured in the UK under ISO 9001 quality-controlled processes and standards
Meets load-bearing requirements for fire and emergency service vehicle access.
Tested for durability, UV resistance, and chemical stability

WHY CHOOSE X-GRID®?

X-Grid® offers a proven, eco-friendly, and high-performance solution for ground reinforcement. It combines sustainability with strength, providing specifiers, architects, contractors, and landscapers with a product that meets modern environmental targets while delivering long-lasting stability.

By replacing traditional impermeable surfaces with X-Grid®, projects can enhance kerb appeal, improve drainage, reduce flooding risks, and create surfaces that are durable, attractive, and environmentally responsible.

By choosing X-Grid®, architects, specifiers, and contractors benefit from:

A long-lasting permeable paving alternative
Simple installation with reduced labour costs
A product that actively supports environmental goals
Proven performance in residential, commercial, and public sector projects

X-Grid's adherence to industry standards and commitment to sustainability make it an ideal choice for forward-thinking, environmentally conscious projects.

COMMON PROJECT EXAMPLES

X-Grid® has proven its versatility across various applications, providing reliable ground reinforcement and gravel retention. As a high-strength, lightweight, and fully permeable system, it offers an innovative solution for projects seeking to balance performance, aesthetics, and sustainability.

With features like easy installation, compliance with SuDS requirements, and support for emergency access standards, X-Grid® enhances the functionality and appeal of various spaces. Some common project examples include:

Grass Reinforcement for fire access routes in education facilities, promoting safety while preserving natural green spaces
Gravel-filled Parking Bays for commercial car parks, ensuring durable and eco-friendly alternatives to traditional paving materials
Stable Pathways through landscaped parks and golf courses, maintaining visual harmony with the surroundings and enabling access for all users
Access Road and ground reinforcement at camping sites, offering a durable and eco-conscious solution for outdoor recreation areas

While these examples showcase X-Grid®'s capabilities, its adaptability is virtually limitless. Its capacity to cater to a wide range of applications across various industries solidifies X-Grid® as a versatile and dependable ground reinforcement solution, positioning it as a top choice for diverse projects.

SUMMARY

X-Grid® is a reliable, sustainable, and cost-effective solution for ground reinforcement, permeable paving, and erosion control. Its high load capacity, fast installation, and environmental credentials make it the preferred choice for construction professionals seeking a modern alternative to traditional surfacing.

X-Grid Ground Reinforcement & Gravel Grid - Compressive Load to Failure Test Report
