Features and benefits:

Suitable for use in flexible walls, rigid walls and floors
Suitable for use around cables, cable bunches, cable trays, cable ladders and non-combustible pipes
Also suitable for use around plastic pipes and insulated non-combustible pipes with the addition of other Quelfire products
Can be used as a blank seal as a head of wall detail
Can be installed into both lined and unlined apertures in partitions walls
Can be installed as a single or double batt seal
Can be pattress fitted / face fixed to walls
Tested with plasterboard ceilings and steel composite profile decks
Can be used in conjunction with Intufoam to allow for deflection head movement.
Manufactured in the UK

Standards and approvals:

Up to two hour fire rating
Fire resistance testing to BS EN 1366-3
EI 30, EI 90, EI 120
Classified to EN 13501-2
Acoustic tested to EN 10140 to 60 dB
CE Marked

Size

1200mm x 600mm, 50mm thick, 140kg/m³ density.

Packaging & Storage

QuelStop Fire Batt is supplied as a 1200x600mmx50mm slab, individually wrapped in polythene and is usually shipped on a pallet and must be stored in dry conditions between +5 and +40C.

Health & Safety

QuelStop Fire Batt is manufactured from stone wool insulation which consists of small fibres. Appropriate protective clothing, including gloves, dust mask, safety glasses, should be worn, especially during cutting and installation, to guard against dust inhalation, eye and skin irritation. For further information, please refer to the Material Safety Data Sheet, available on request.

Installation:

QuelStop Fire Batt is used to maintain the fire integrity of compartment walls or floors, typically where oversized holes have been formed for services. A single or double batt may be required depending on a number of factors and it can also be fitted as a pattress fit (or face fit) too.

QuelStop Fire Batt is always installed in conjunction with QuelStop Intumescent Acrylic Sealant which is applied to all cuts, joints and exposed edges.

Where combustible, non-combustible services and insulated services penetrate the QuelStop Fire Batt seal the following additional products may be required:

QuelCoil Intuwrap
QWR Fire Collar
QRS Fire Sleeve
QuelStop HPE Graphite Sealant
QuelStop Intumescent Acrylic Sealant
QIF Insulated Fire Sleeve
QI Intufoam

For full details on the size of seals, the spacing of services, batt overlap requirements, seal details etc refer to all available documentation.

QuelStop Fire Batt can be installed in many different ways. In all cases the surfaces, letterbox and services must be clean of contaminants and dust free and the batt must be installed with QuelStop Intumescent Acrylic Sealant and in conjunction with the supporting documentation provided.

Certificate of Constancy of Performance - QB50 QuelStop Fire Batt
