Total bitumen warm green roof system PLUS, incorporating torch-on bitumen capping sheet with self-adhered bitumen underlayer, insulation and self-adhered bitumen air and vapour control layer (AVCL).

Bauder Total Green Roof System PLUS (BTGRS PLUS) is suitable for a variety of applications on both new build and refurbishment projects and can be used in warm, cold and inverted roof scenarios.

BTGRS PLUS is deemed ‘unrestricted’ and suitable for use on any part of a roof.

Plus points:

Two-layer 8.7 mm combined waterproofing.
Atactic polypropylene (APP)/ styrene-butadiene-styrene (SBS) dual modified bitumen 5.2 mm cap sheet with glass-polyester composite reinforcement.
SBS modified elastomeric bitumen, used on the underside, provides flexibility to cope with European climatic extremes of between -40°C to +150°C. Tested to EN 1109 & EN 1110 and stated on the BBA certificate.
APP modified bitumen, used for the upper coating, offers a life expectancy in excess of 35 years according to section 12 of the BBA certificate.
Incorporates self-adhesive membranes.
Safe2Torch detailing design.
Range of guarantee packages to fulfil cover requirements for the project (dependent on system/ product selection). For more information contact Bauder's technical department for a sample guarantee outlining cover level, terms and conditions.

Verified properties:

CCPI Verification 0007700016/1025: This systems CCPI mark provides accuracy of data delivering assurance to specifiers.
Fire properties – membranes deemed “unrestricted” in certain circumstances.
Service life > 35 years as stated in BBA certificate.
EPD Certifications for: Bitumen Membranes, PU Insulation - Aluminium Facing, BauderROCK Insulation, BauderGLAS insulation.

Bauder BTRS-BTGRS Plus CCPI
