Zip HydroTap Classic Accessibility - Water Tap

Name: Zip HydroTap Classic Accessibility - Water Tap
Brand: Zip Water
SKU: asrHhVBofTkgiXGX8hNx9z

Verified by manufacturer 4 months ago

Zip Water

Third party certifications:

EPD
Certificate type
WRAS
Certificate type

Instant filtered boiling and chilled water for visually impaired, wheelchair and limited dexterity users.

Jump to:

+44 (0)345 6 005 005 Website

Application

Suitable for commercial applications in catering environments. Disability friendly controller design.

Description

The Disability Friendly HydroTap comes with the addition of an easy to use controller to enable access to instant filtered boiling and chilled water for visually impaired, wheelchair and limited dexterity users.

Features and benefits:

Slanting design to prevent accidental dispense.
Large, convex buttons to make it easier to dispense water for those with limited dexterity.
Choice of install location to ensure positioning for easy wheelchair access.
Bright, illuminated fascia panels work to aid visually impaired users – there is a choice of two colour variants available in the kit.

General information

Color	Silver
Finish	Chrome Guidance for specification option: Bright chrome.
Material	Steel Stainless steel
Shape	Other
Length	520 mm
Width	500 mm
Height	373 mm
Warranty description	Two year

Uniclass	Pr_40_70_23_42 Instant boiling and cold water tapsPrimary
CAWS	N11/30 Sinks, taps, traps and wastes N12/380 Sinks, taps, traps and wastes N12/380 Sinks, taps, traps and wastes N11/350 Sinks, taps, traps and wastes

Product range	Instant Boiling and Chilled Tap

Specification data - Instant boiling and cold water taps

Water	Boiling and chilled.
Duty	-
Hot cups	240.
Cold cups	175.
Dimensions	373 x 500 x 490-520 mm. Manufacturer guidance (Height x width x depth) Unit:
Electrical connection	-
Power	Manufacturer's standard. Guidance for specification option: Command centre power rating: 2.13 kW at 230 V a.c. Booster power rating: 2.2 kW at 230 V. Voltage supply: 13 amps. Power supply requirements: 2 x 13 amp socket outlet. Cable length: 1.8 m fitted with UK standard three-pin plug. Installation: Must comply with current IEE regulations.
Voltage	230 V.
Water inlet	Cold feed. Guidance for specification option: Supply connection (hot and cold): 1 x isolated 1/2" BSP fitting (flexible supply hoses included). Manufacturer guidance (supply required):
Safety features	Boiling isolation, cool touch tap and safety lock. Guidance for specification option: The boiling point is factory set to 98°C to avoid spluttering steam.

WaterPressureRange	1.7-5 bar.
Weight	28 kg (empty); 33 kg (full).
Design	Bright chrome.
Rotation	Fixed.
Temperature	Boiling: 98°C; chilled: 6-10°C. Guidance for specification option: Factory temperature.
Filtration	0.2 µm filter cartridge.
Flow rate	4 L/m.
RefrigerantClass	R290.
Installation	35 mm. Manufacturer guidance / Installation hole cut size:
Construction	Stainless steel. Manufacturer guidance Tank material:

Sustainability data

Contains Red List materials	No
Country of material origin	Australia
Country of product manufacture	Australia
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	199 kg CO₂ eq/unit
Recyclability	99.8%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
