York - Freestanding Bath
Verified by manufacturer 4 months ago
Freestanding bath, 145 L capacity.
Application
Luxury freestanding bath suitable for domestic and hospitality settings.
Description
Victorian-inspired freestanding bath.
Features and benefits:
- Features a deep, double-ended bathing well and an elegant pedestal base hiding all the waste plumbing.
- Made with QUARRYCAST™ a unique blend of Volcanic Limestone™ and high-performance resins.
- Delivers unrivalled strength, durability, and beauty.
- Available in a range of RAL colours.
General information
Color | White |
Finish | Gloss |
Material | Limestone Stone |
Shape | Oval |
Length | 1741 mm |
Width | 795 mm |
Height | 616 mm |
Warranty description | Eight year Guidance for specification option: Commercial use. 25 year Guidance for specification option: Residential use. |
Uniclass | |
CAWS | N13/35 Baths N13/355 Baths |
Specification data - Baths
Form | Free-standing. |
Materials | QUARRYCAST™ volcanic limestone. |
Colour | White. |
Size | 1741 x 795 mm. |
Volume to overflow (maximum) | 145 L. |
Water supply, overflow and waste holes | |
Water supply | No tap holes. |
Weight | 67 kg. |
Dimensions – height | 616 mm. |
Material Finish | Gloss. |
Recommended discharge pipe | Not required. K-30-xx. K-31-xx. Manufacturer guidance(Recommended wastes): |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Literature
EU_York_2022
Case studies
Kimpton Fitzroy London UK (York)
Waldorf Astoria Amsterdam (York)
