YewdaleDefiant® C45 Cassetted Roller Blind with Low Voltage Electric Motor and Side Channels

Verified by manufacturer 3 months ago

C45-60: 60 mm

Yewdale Corporation Ltd Variant:

Low voltage cassetted roller blind.

Jump to:
BOS
+44 (0) 1268 570900 Website

Application

A luxury addition to any environment.

Description

C45-60**C45-90


Slim profile, cassetted electric roller blind with 24v DC motor.


Features and benefits:

  • Features a low voltage 24v DC motor as standard.
  • Square or rounded headbox available.
  • Cassette accommodates a 40 mm grooved aluminium barrel.
  • The motor is controlled by a switch which may be surface or flush mounted (not supplied as standard).
  • Fabric is locked into a groove in the barrel with studs fitted at the edge of fabric to retain it within side channels.
  • Aluminium bottom bar.
  • Black or white hardware as standard.
  • RTS control as standard.
  • Quick and simple installation following the Yewdale goalpost installation.

General information

Color

Black

White

Manufacturer guidance

Any RAL colour available

Material

Aluminium

PVC

Polyester

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Lifetime

Uniclass

Pr_30_59_07_72 Roller blindsPrimary

CAWS

N10/70 Blinds

N10/240 Blinds

Product range

Blinds

Specification data - Roller blinds

Dimensions (minimum width x depth)

533 x 1500 mm.

Headrail

-

Material

Aluminium.

Colour

Black.

Guidance for specification option:

Hardware

White.

Guidance for specification option:

Hardware

Manufacturer guidance

Any RAL colour available

Blinds

-

Material

PVC.

Polyester.

Manufacturer guidance

Various available on request

Finish

YewdaleDefiant Eden Daylight Fabric.

YewdaleDefiant Eden Blackout Fabric.

YewdaleDefiant Roe Fabric.

YewdaleDefiant Dart Fabric.

YewdaleDefiant Thames Fabric.

YewdaleDefiant Roach.

Guidance for specification option:

Not available for vertical blinds

Colour

-

Manufacturer guidance

Various, on request

Tube

-

Material

Aluminium.

Diameter

40 mm.

Operation

24 V d.c. motorized.

Accessories

Surface mounted switch.

Flush mounted switch.

Tracker Fabric Retaining System.

Side channels

55 x 13 mm.

Sustainability data

Country of product manufacture

United Kingdom
