XP95 Input/Output Module - Three Channel - Isolating - Monitors

Verified by manufacturer 2 months ago

Apollo Fire Detectors Ltd

An addressable three channel loop powered Input/ output Unit providing three voltage-free relay outputs and three monitored switch inputs.

Jump to:
BOS
+44 (0)23 9249 2412 Website

Description

The Three Channel Input/ output Unit provides three voltage-free, single pole, changeover relay outputs and three monitored switch inputs.


Features and benefits:

  • Supervises one or more normally open switches on each of the three inputs.
  • Loop-powered.
  • Capable of switching up to 30V at 1A on each of the three outputs.

General information

Color

White

Finish

Gloss

Material

Polycarbonate

Nickel

Stainless steel

Acrylonitrile butadiene styrene (ABS)

Shape

Rectangle

Circle

Length

75 mm

Width

175 mm

Height

250 mm

Warranty description

Ten year

Uniclass

Pr_75_51_52_15 Control and protective switching devicesPrimary

Sustainability data

Material

Polycarbonate

Nickel

Stainless steel

Acrylonitrile butadiene styrene (ABS)

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
IFC

IFC2X3

2

Revit

Revit 2016

4
