wedi Sanbath Floating Wash Basin - Wall hung wash basin with channel drain
Verified by manufacturer 6 months ago
BBA Agrément Certificate
Certificate type
Custom-made washbasin with linear drainage.
Application
For private and commercial use indoors. For use with wedi installation frames.
Description
Custom-made washbasin with linear drainage.
Features and benefits:
- Stylish design.
- Robust.
- Custom width between 500 and 1300 mm.
- Four channel lengths to choose from.
- Choice of channel covers. (standard, exclusive or tileable).
- Load capacity up to 150 kg.
- Part of the Sanbath range.
General information
Color | Grey |
Finish | Cement Unfinished |
Shape | Rectangle Square |
Size | Manufacturer guidanceBespoke made to order product |
Length | Bespoke Manufacturer guidanceBespoke made to order product |
Width | Bespoke Manufacturer guidanceBespoke made to order product |
Height | Bespoke Manufacturer guidanceBespoke made to order product |
Warranty description | Ten year |
Uniclass | |
CAWS | N13/30 Washbasins N13/335 Washbasins |
SKU Code | 073606098 |
Specification data - Wall-hung washbasins
Classification data | |
Form | Wall-hung wash basin. Guidance for specification option: For use with installation frame, finished with wedi building board. Consult manufacturer for details. |
Materials | |
Body | Manufacturer's standard. |
Finish and colour | Grey. |
Size | Manufacturer guidanceInsert required width in mm; 500–1300 mm. Depth: 500 mm. Height: 120 mm. |
Water supply, overflow and waste holes | |
Water supply | Manufacturer guidanceInsert requirements. |
Overflow | None. |
Waste | 300 mm channel. 700 mm channel. 800 mm channel. 900 mm channel. |
Integral accessories | Stainless steel channel cover. Guidance for specification option: Standard. Exclusive brush stainless steel channel cover. Tileable channel cover. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Germany |
Country of product manufacture | Germany |
Recyclability | XPS core fully recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 25 % |
Product certifications
Literature
Literature type
2022 wedi World of Systems brochure
Bathroom Advice Brochure
wedi at a glance 2022
