Description

The pre-fabricated cladding for front wall installations.

  • Simple and quick to install
  • wedi I-Board (1200 x 1245 x 20 mm) is a pre-fabricated element for the cladding of wall-mounted WCs. With a width of 1,200 mm, it can easily be adapted to virtually all needs.
  • Despite the the I-Board being light weight, it is extremely strong and stable (up to 400 kg weight load from a tile size of 10 x 10 cm).
  • The installed cladding board can be tiled directly without further pre-treatment.

General information
Finish

resistant and glass fibre reinforced cement coating

Color

grey

Features

wedi I-Board, WC installation systems cover, including spaces for WC piping, brackets and screw set

Material

A waterproof extruded polystyrene rigid foam core with a special, resistant and glass fibre reinforced cement coating

Shape

Rectangle

Size

1200 x 1245 x 20 mm

WarrantyDescription

available on request

Uniclass 2015
Extruded polystyrene (XPS) boards (Pr_25_71_63_29)Primary
Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.1
Revit
Revit 2017 1 2.1
