Washbasin ViCare 711961
Verified by manufacturer over a year ago
71196101
71196101
Rectangular washbasin.
Application
Wall mounted.
Description
Rectangular washbasin.
Features and benefits:
- Previously O.novo Vita.
- Sanitary ceramics.
- Wheelchair-compatible.
- DIN 18040, EN 31, EN 14688.
- In accordance with DIN 18040.
General information
Color | White |
Finish | Gloss |
Material | Ceramic |
Shape | Rectangle |
Length | 600 mm |
Width | 490 mm |
Uniclass | |
CAWS | N13/335 Washbasins N13/30 Washbasins |
SKU Code | 71196101, 711961R1 |
Specification data - Wall-hung washbasins
Classification data | |
Standard | To EN 31 and BS EN 14688. |
Form | Wall-hung washbasin. |
Connecting dimensions | To BS EN 31. |
Materials | |
Body | Sanitary ceramic. |
Finish and colour | White alpin, gloss. |
Size | 600 x 490 mm. |
Water supply, overflow and waste holes | |
Water supply | Single tap hole, centred. Guidance for specification option: Suitable for 3-hole tap fittings, central tap hole punched out. |
Overflow | None. Guidance for specification option: Without overflow, Please note: un-closable outlet valve must be used with models without overflow. |
Waste | Bottom waste outlet. No chainstay hole. |
Weight | 17.86 kg. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
 ARCHICAD | - | 1 |
 OBJ | - | 1 |
 SketchUp | - | 1 |
 3Ds Max | - | 1 |
