Visqueen TorchOn Tanking Membane

Verified by manufacturer 3 months ago

Visqueen Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

  • DoP

    DoP

    Certificate type

Robust waterproofing membrane for heavy duty tanking applications.

Jump to:
BOS
+44 (0) 333 202 6800 Website

Application

  • Suitable for use as a Type A Barrier Membrane for above and below ground applications such as basements, retaining walls and lift pits.
  • It is also suitable for use in all types of buildings to prevent the ingress of harmful levels of ground gases e.g. methane, carbon dioxide and radon.

Description

A modified bitumen rubber tanking membrane. It has a sanded finish to the top surface and a heat dispersible film on the underside.


Features and benefits:

  • The roll is supplied 1m x 8m.
  • BBA certified - third party accreditation.
  • Type A Barrier Membrane (Tanking Membrane) - resistant to ground water in accordance with BS 8102:2022.
  • Complies with the methane gas transmission rate, mass per unit area and thickness requirements of BS 8485:2015 + A1:2019 - industry standard for methane and carbon dioxide protection.
  • Flexible - easy to detail and install on site.
  • Multi functional - also acts as a radon and damp proof membrane.
  • Heat bonded application - no jointing tapes required.
  • Heat bonded application - ideal for cold and damp conditions.

General information

Color

Black

Finish

Sanded

Material

Bitumen

Shape

Rectangle

Length

8000 mm

Width

1000 mm

Warranty description

Guidance for specification option:

See manufacturer's insurance document for warranty details. Consult manufacturer for further information.

Uniclass

Pr_25_57_08_08 Bitumen sheetsPrimary

CAWS

J40/270 Fully bonded bitumen damp proofing/ tanking sheet

Specification data - Bitumen sheets

Product Reference

Visqueen TorchOn Tanking Membrane

Accessories

Heavy Duty Protection Boards.

Guidance for specification option:

For protecting membranes from damage from following trades.

High performance tanking primer.

Visqueen Protect&Drain.

Preformed Pipe Cloak (Top Hat) Units.

Guidance for specification option:

For airtight seals around service pipe penetrations.

Zedex DPC Jointing Tape.

Standard

CE Mark EN 13969:2004.

Third party accreditation

BBA 14/5121.

Weight

4.5 kg/m².

Length

8 m.

Width

1 m.

Minimum

3.5 mm.

Top

Sanded finish.

Underside

Heat dispersible film.

Reaction to fire

F class.

Watertightness

60 kPa.

Resistance to static loading - 20kg load

20 kg.

Tensile elongation property

35%.

Application temperature

Guidance for specification option:

Recommended should not be used below 5°C.

Methane permeability

<40 mls/m²/d/atm.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Bitumen

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit

Revit 2015

4

IFC

IFC2X3

2

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

BBA Certificate Visqueen TorchOn Tanking Membrane

DoP

DoP

Tanking CE Visqueen TorchOn Tanking Membrane Declaration of Performance

DoP

DoP

Tanking UKCA Visqueen TorchOn Tanking Membrane Declaration of Performance
