Description

The over door plate is used to give an audible and visual warning as to which disabled WC requires assistance, it should be mounted either on the wall or ceiling above the door of the disabled WC . The over door plate is built in a single gang brushed stainless steel plate as standard with a blue halo indicator for the visual alarm and a buzzer for the audible alarm.

For simplicity all wiring is a standard two core cable, the wiring order of the plates is not fixed and therefore can be wired in any order to provide cable routeing flexibility. Each plate has two sets of two part terminals allowing simple cable connections and also a complete first fix solution.

General information
Features

Blue LED halo indicators, all wiring is two core and units can be wired in any order, high quality two part terminals suitable for 2.5 mm CSA cable, optional NiMH rechargeable monitored backup battery, 1 zone controller with accept button for remote indication

Material

Stainless steel

Shape

Square

Size

86 x 86 mm

Uniclass 2015 Assistance call indicator units (Pr_75_75_04_01)
Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.1
Revit
- 1 2.1
Download now from NBS National BIM Library
