ViCare Washdown WC, Horizontal Outlet 4620H7
Verified by manufacturer 8 months ago
Washdown toilet.
Application
Suitable for washdown toilet.
Description
Washdown toilet.
Features and benefits:
- Previously O.novo Vita.
- Sanitary ceramics.
- Complies with EN 997, DIN 18040.
- Composed of DirectFlush 4620 R0 XX hollow bottom bowl, side power supply, QuickRelease hinged flap and SoftClosing 9M67 S1 T1, Tank with mec. key ECO FLUSH chrome 5760 21 XX.
- Flush volume 3/ 6 L.
- LEED 2.
- European water label 3,75 L.
- Please order toilet seat separately.
General information
Color | White |
Material | Ceramic Guidance for specification option: Sanitary ceramics |
Shape | Oval |
Width | 360 mm |
Uniclass | |
CAWS | N13/10 WC pans and flushing arrangements N13/300 WCs and cisterns |
Specification data - WC suites
Standards | |
Cisterns | To BS EN 997. |
Pans | To BS EN 997. |
Form | Floor-standing, washdown. |
Materials | |
Body | Ceramic.Guidance for specification option: Sanitary ceramics. |
Finish and colour | White. |
Sizes | |
Cistern capacity | 3/6 L. |
Pan height | 460 mm. |
Weight | 44.5 kg. |
Width | 360 mm. |
Depth | 710 mm. |
Outlet | Horizontal. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 SketchUp | - | 1 |
 IFC | - | 1 |
 OBJ | - | 1 |
 Revit | - | 1 |
 3Ds Max | - | 1 |
 ARCHICAD | - | 1 |
