Vertical Solar Shading Blade System - Solar Shading/Brise Soleil
Verified by manufacturer 8 months ago
Aluminium solar shading system.
Application
Suitable for any application that requires solar shading across a window, this could be a hospital, care home, school or office building.
Description
The solar shading structure comprises of a light weight, rust resistant aluminium frame that can be powder coated to any standard RAL colour and aluminium ellipsoid blades (200 mm).
Vertical unsupported span is 3000 mm.
UKCA marked to BSI-EN 1090-1 - Execution of Steel and Aluminium Structures.
General information
Color | Black Blue Green Grey Red |
Finish | Powder-coated |
Material | Aluminium |
Shape | Rectangle Other Guidance for specification option: Elliptical. |
Length | Bespoke |
Width | 200 mm Guidance for specification option: Blade. |
Height | Bespoke |
Warranty description | Ten year |
Uniclass | |
CAWS | L10/55 Brises-soleil L10/670 Brises-soleil |
Specification data - Aluminium brise-soleil units
Support arms | |
Material | Extruded aluminium profiles and structure to BS 1474. |
Finish | Polyester powder coating to BS 6496. |
Colour | Guidance for specification option: Consult manufacturer and insert requirements. Powder-coated to any standard RAL colour. |
Size | Guidance for specification option: Bespoke. Consult manufacturer and insert requirements. |
Array louvre blades | |
Profile | Rectangular.Elliptical. |
Size | 200 mm. |
Material | Extruded aluminium profiles and structure to BS 1474. |
Finish | Polyester powder coating to BS 6496. |
Colour | Guidance for specification option: Consul manufacturer and insert requirements. Powder-coated to any standard RAL colour. |
Fixing | Stainless steel self-tapping screws and stainless steel bolts/ nuts as recommended by Twinfix. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | 100% |
