Venetian Blind 5000 Series

Name: Venetian Blind 5000 Series
Brand: InterLace
SKU: hy3hz8eQbBSW34k37BEkaN

Verified by manufacturer 2 months ago

InterLace

Third party certifications:

CHAS
Certificate type
ISO 9001 Quality Management
Certificate type
Constructionline
Certificate type
Acclaim Accreditation
Certificate type
Constructionline Gold
Certificate type
Alcumus SafeContractor
Certificate type

The Venetian Blind 5000 Series comes in metal or timber slat finishes with various slat sizes and control options.

Jump to:

01223 897809 Website

Application

For demanding environments. Suitable for use on vertical windows, sloping windows, sealed in secondary glazing and internal screens, large curtain walling, doors and roofs (tilt only).

Description

The mechanism is geared for lightweight and easy use. Available in 16 mm and 25 mm, 35 mm and 50 mm slat sizes for internal use and 80 mm for external systems.

Features and benefits:

Refined.
Well-engineered.
Strong, attractive headrail.
Metal slats tested to demanding standards.

General information

Color	- Manufacturer guidance Subject to material specified, from standard range.
Material	Metal Timber
Length	2500 mm 3000 mm
Width	16 mm 25 mm 35 mm 50 mm 80 mm Manufacturer guidance of slat
Warranty description	One year Guidance for specification option: 12 months from the date of installation.

Uniclass	Pr_30_59_07_94 Venetian blindsPrimary
CAWS	N10/70 Blinds N10/240 Blinds

Specification data - Venetian blinds

Standards	To BS EN 13120 and BS 5867.
Position	Internal to vertical glazing.
Dimensions (minimum width x depth)	2400 x 2500 mm. 3000 x 2500 mm. 2400 x 3000 mm. 3000 x 3000 mm. Manufacturer guidance 2400 mm, 3000 mm (maximum width), 2500 mm, 3000 mm (maximum drop).
Slats	-
Width (maximum)	16 mm. 25 mm. 35 mm. 50 mm. 80 mm.
Material	Timber. Metal.
Finish	Guidance for specification option: Subject to material specified.
Headrail	-
Material	Powder coated extruded aluminium.
Operation	Manual cord and wand operation. Electric motor operation (24v). Manual crank operation. Electric motor operation (240v). Manual mono chain operation. Manual tilt only operation. Manual mono cord operation.
Operating effort	To BS EN 13120, class 1.
Testing	Solar transmittance.
Mechanism endurance	To BS EN 13120, class 1.

Sustainability data

Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Metal Timber
Recyclability	- Manufacturer guidance Subject to fabric specified. Recyclable where facilities exist.
