Unilateral Two Single Pocket Doors into the same Pocket
Description

A sliding door system with a unilateral frame allowing two opposite-handed doors to slide into the same pocket. It requires the dimension of only a single frame whilst hosting two parallel doors, ideal when only short wall spaces are available in corridors and hall entrances, exploiting even the tightest of spaces.

Features:

  • Features:
  • The door post, pocket and track assemble together and are inserted into the stud work as a complete unit which helps to ensure the door will run true and in line.
  • Doors slides into the same pocket in the wall.
  • Wide range of sizes to suit standard UK door sizes. Bespoke sizes available.
  • Door panels up to 100 kg.
  • Suitable for use with 35 or 44 mm thick doors.
  • Doors, plasterboard and final architrave not included.

Advantages:

  • Quick and easy to assemble and install.
  • Complete with full wooden jamb kit for a professional finish.
  • Maintenance-free track and runners.
  • Fully extractable track, no need to break into the wall should you ever want to remove it.
  • Fully adjustable front and rear doorstop.
  • Anti-warp door profile, ensuring a long-term, smooth sliding operation.
  • Self-centring floor guide with anti-warp profile.

General information

Size

Features

Features

The door post, pocket and track assemble together and are inserted into the stud work as a complete unit which helps to ensure the door will run true and in line

Doors slides into the same pocket in the wall

Wide range of sizes to suit standard UK door sizes. Bespoke sizes available

Door panels up to 100 kg

Show more

Uniclass 2015

Pr_30_59_24_80 Sliding door and partition setsPrimary

CAWS

L20/520 Sliding doors

L20/525 Sliding pocket doors

P21/10 Quantities and locations

P21/350 Door track and running gear

Specification data - Sliding door and partition sets

Product Reference

Unilateral Two Single Pocket Doors into the same Pocket

Size

See Options below and insert requirement.

Door furniture

OSO8

Polished brass simple flush pull

OSC4

Antique brass simple flush pull.

OSC2

Polished chrome simple flush pull.

OSC1

Satin chrome simple flush pull.

OSO3

Polished brass bathroom lock.

OSA

Antique brass bathroom lock.

OSO1

Polished chrome bathroom lock.

OSS

Satin chrome bathroom lock.

Accessories

Not required

ECLISSE BIAS®

ECLISSE BIAS® DS

e-Motion motor

Self closing mechanism

Soft close

Standard product features

Finished wall thickness:

175 mm.

Product Options

Size:

The following frame sizes (in mm) are available:

  • 1952 x 2056: To suit 610 x 1981 mm door. Clearance: 585 x 1971 mm.
  • 2204 x 2056: To suit 686 x 1981 mm door. Clearance: 661 x 1971 mm.
  • 2456 x 2056: To suit 762 x 1981 mm door. Clearance: 737 x 1971 mm.
  • 2608 x 2056: To suit 838 x 1981 mm door. Clearance: 813 x 1971 mm.
  • 2882 x 2056: To suit 914 x 1981 mm door. Clearance: 900 x 1971 mm.
  • 1982 x 2115: To suit 626 x 2040 mm door. Clearance: 600 x 2030 mm
  • 2282 x 2115: To suit 726 x 2040 mm door. Clearance: 700 x 2030 mm.
  • 2582 x 2115: To suit 826 x 2040 mm door. Clearance: 800 x 2030 mm.
  • 2882 x 2115: To suit 926 x 2040 mm door. Clearance: 900 x 2030 mm.
  • 3182 x 2115: To suit 1026 x 2040 mm door. Clearance: 1000 x 2030 mm.

Accessories:

  • ECLISSE BIAS®: soft close anti-slam device with 40 kg. soft closing.
  • ECLISSE BIAS® DS: Bi-directional safety soft close anti-slam device with 40 kg. soft closing.
  • E-Motion: Linear motor open/close Can be operated by push button, infra red detector, remote control or radar sensor activator.
  • Self closing mechanism: Open the door and it closes by itself.
  • Soft close: Slide the door towards the close position and the soft close takes over.
