Uni Sheet
Application

Suitable for interior use, including schools, hospitals, museums, offices and other places of work. Classification (to EN ISO 10874 (EN 685)): 23 (Residential); 34 (Commercial); 43 (Industrial).

Description

Bold uniform colour smooth, non-slip, resilient rubber flooring sheet with PRO surface treatment.

Features and benefits:

  • The PRO surface treatment has UV linked polymeric coating technology. The coating finish protects the surface, improves performance and reduces the need for cleaning and maintenance.
  • Available as X-Elastic acoustic flooring (specified separately).
  • Also available in tile format (specified separately).

Application:

Suitable for interior use, including schools, hospitals, museums, offices and other places of work. Classification (to EN ISO 10874 (EN 685)): 23 (Residential); 34 (Commercial); 43 (Industrial).

General information

Color

U00 Carbon

U11 Gold

U13 Firebrik

U14 Mahogany

U16 Avio

U17 Metal

U18 Grape

U20 Smoke

U21 Eiffel

U26 Steel

U27 Sand

U36 Silk

U39 Olive

U54 Greige

U55 Stone

U56 Navajo

U87 Cream

U95 Summer

U99 Ice

U105 Tangerine

U106 Bamboo

U107 Lime

U108 Canary

U109 Pearl

U110 Slate

U123 Brown

U124 Fossil

U128 Cashmere

U129 Horizon

U130 Crimson

Features

Smooth, non-slip resilient rubber flooring tile with marbled effect and PRO surface treatment

Finish

Smooth

Material

Rubber

Shape

Rectangle

Size

3 x 1900 x 10 000 mm

Uniclass 2015

Pr_35_57_71_80 Smooth rubber sheetsPrimary

CAWS

M50/150 Sheeting

M50/20 Sheeting

Specification data - Smooth rubber sheets Enhanced data

Product Reference

Uni Sheet

Standard

To BS EN 1817 and BS EN 14041

Use class

To BS EN ISO 10874 class 23/ 34/ 43

Slip potential

-

Slip Potential - Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

DS

Width

1900 mm

Length: 10 m.

Thickness

3 mm

Colour and pattern

U00 Carbon

U11 Gold

U13 Firebrik

U14 Mahogany

U16 Avio

U17 Metal

U18 Grape

U20 Smoke

U21 Eiffel

U26 Steel

U27 Sand

U36 Silk

U39 Olive

U54 Greige

U55 Stone

U56 Navajo

U87 Cream

U99 Ice

U105 Tangerine

U106 Bamboo

U107 Lime

U108 Canary

U109 Pearl

U110 Slate

U123 Brown

U124 Fossil

U128 Cashmere

U130 Crimson

Weight

5.2 kg/m²

Technical characteristics to EN 12199

-

Hardness (to ISO 7619)

Shore 85

Residual indentation (to EN/ISO 24343-1 (EN 433))

0.04 mm

Abrasion resistance (to ISO 4649)

165 mm³

Dimensional stability (to EN/ISO 23999 (EN 434))

±0.30%

Flexibility (to EN/ISO 24344 Met. A Ø 20 mm (EN 435))

Comply

Colour fastness to artificial light (to ISO 105-B02 Met. 3)

Comply

Cigarette burn (to EN 1399)

Comply

Technical characteristics to EN 14041

-

Fire behaviour (to EN 13501-1)

Class Bfl–s1

Technical characteristics, other

-

Toxicity of decomposition gases (to DIN 53436 at 350°C)

Not toxic

Resistance to stains (to EN/ISO 26987 (EN 423))

Resistant

Depending on concentration and time of contact: for specific agent contact manufacturer.

Ramp slip resistance (to DIN 51130)

R9

Thermal resistance (to EN 12667)

0.020 m²K/W

Thermal conductivity (to EN 12667)

0.15 W/m·K

Electrical resistance (to EN 1081 Met. A)

>10^10 ohms

Electrostatic charge (to EN 1815)

≤2 kV (antistatic)

Reduction of sound due to treading (to ISO 10140-3)

Up to 10 dB

Castor chairs (to EN 425)

Suitable for W castors

VOC emissions (CA Section 01350)

Comply

VOC emissions (AgBB)

Comply

Standard product features

Colour:

30 options.

Features:

Smooth, non-slip resilient rubber flooring sheet with PRO surface treatment.

Finish:

Smooth.

Material:

Rubber.

Shape:

Rectangular.

Size:

3 x 1900 x 10 000 mm.

Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.1
Revit
- 1 2.1
Download now from NBS National BIM Library
Literature
Third party certifications

Additional certifications:

  • Émissions dans l’air intérieur: A+
  • UL: Environmental Product Declaration - Certified
  • UL: GREENGUARD - Certified
  • UL: GREENGUARD Gold - Certified
  • Blue Angel: RAL UZ 120 - Certified
  • GECA: GECA 25-2011v2 - Certified
