Ultra Corner Protection
Verified by manufacturer 7 days ago
PVC-U corner protection with enhanced strength gained from an aluminium core, available in 90 and 135° angles and a range of sizes and colours.
Application
Suitable for use in busy heavy duty areas where motorized tugs and trucks may be in use such as:
- Hospitals.
- Warehouses.
- Schools.
Description
PVC-U corner protection with enhanced strength gained from an aluminium core, available in 90 and 135° angles and a range of sizes and colours.
Features and benefits:
- Fire tested to a range of standards including BS 476-6 and -7.
- Available in 2500 and 1250 mm lengths.
- Choice 90 or 135° angles.
- Wide range of colour options.
- Reinforced with inner aluminium core.
- Screw fixed.
- Stop ends.
- Low VOC product.
General information
Color | Beige Black Blue Brown Cream |
Finish | Textured |
Material | PVC-U Aluminium Rubber |
Shape | Other |
Length | 2500 mm 1250 mm |
Width | 75 mm |
Height | 75 mm |
Uniclass | |
CAWS | P20/170 Proprietary P20/30 Proprietary |
Specification data - Corner guards
Supplied by | Yeoman Shield |
Material | PVC-U, aluminium and rubber. Guidance for specification option:
|
Fire rating | To BS EN 13823. To BS EN ISO 11925-2. To BS EN 13501-1, B, s2, d0. To BS 476-7, Class Y1. To BS 476-6, Class 0. |
Finish | |
Colour | Manufacturer guidanceManufacturer offers a wide selection of 48 colours; consult manufacturer for more details and insert requirements. |
Texture | Stippled. |
Size | 75 x 75 x 2500 mm. 75 x 75 x 1250 mm. Guidance for specification option: Cost saving pack. |
Fixing | Screws. Guidance for specification option: Consult manufacturer for more details and insert requirements. |
Angle | 90°. 135°. |
Sustainability data
Material | PVC-U Aluminium Rubber |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
Literature
Yeoman Shield General Information Sheet for Products
