TS Rail (External Wall Insulation System) - Cavity External Wall Insulation System
Verified by manufacturer 9 months ago
Enviromin mineral finish
Enviromin mineral finish
EWI for use on lightweight metal-framed or timber-framed structures.
Application
EWI for new build housing.
Description
EWI for use on lightweight metal-framed or timber-framed structures.
The product consists of a pre-engineered insulation board that sits within a PVC rail framework mechanically fixed to a sheathing board which provides a drainage cavity behind the insulation system.
Features and benefits:
- Fire rated options from A2-s1 do to B-s1 do (dependent on the system).
- EPS system tested to BS 8414.
- Systems available for both light steel framing (LSF) and timber frame, BBA certified (see below).
- Options for compliance with building guarantee companies.
- Supports a high level of acoustic performance in through wall construction.
- Brick and render options available, in a wide range of colours and finishes.
- U-values achievable down to 0.11 W/m²K.
For BBA certification, see:
- 05/4206, product sheet 3 (EPS for LSF);
- 17/5447, product sheet 2 (EPS for timber frame);
- 17/5447, product sheet 1 (mineral wool for timber frame).
General information
Color | White Cream Blue Yellow Green |
Finish | Textured Guidance for specification option: Flexible brick slips. |
Material | Expanded polystyrene (EPS) Guidance for specification option: Grey EPS. Mineral wool |
Warranty description | Ten year 25 year Guidance for specification option: PAS 2035. |
Uniclass | |
CAWS | M21/20 External wall insulation systems M21/210 Rendered external wall insulation systems |
Specification data - External wall insulation systems
Classification data | |
Support rails and brackets | |
Fixing method | |
Bracket fixings | Manufacturer's standard. |
Boards | |
Material | Sheathing board (minimum 9 mm) with SPSenvirowall Fabrock 271. |
Fixings | Manufacturer's standard. |
Insulation | |
Material | Expanded polystyrene (EPS) rail system insulation. Mineral wool rail system insulation. |
Additional mechanical fixings | Rail system. |
Fire barriers and stops | |
Material | Rockwool facade lamella fire break. |
Fixings | Manufacturer's standard. |
Render carrier or reinforcement | |
Material | High polymer modified basecoat with reinforcing mesh. |
Mesh size | Manufacturer's standard. |
Fixings | Manufacturer's standard. |
Render | |
Application | Finish coat. |
Material | Enviromin mineral finish. Guidance for specification option: High-performance cement-based and polymer modified through-coloured mineral thin coat render. Consult manufacturer for full details. |
Decorative finish | Textured, standard. |
Colour | WH89 White. SC75 Cream. SC69 Cream. BL57 Blue. CG56 Grey. LY82 Light Yellow. GR62 Green. Bespoke. Manufacturer guidancePastel shades. |
Sustainability data
Material | Expanded polystyrene (EPS) Guidance for specification option: Grey EPS. Mineral wool |
Recyclability | EPS and mineral wool recycle from site schemes |
