Application

  • Foundations.
  • Basements.
  • Roofs and plaza decks.
  • Lift shafts, pits.
  • Service reservoir roofs.
  • Car parks.
  • Subways.
  • Bathrooms.
  • Balconies.

Description

A self-adhesive sheet membrane constructed from an oriented cross laminated high density polyethylene sheeting and a bitumen-polymer adhesive compound. The product is a tough and durable self-adhesive sheet with an overall thickness of 1.5 mm. The unique selvedge feature enables a fast and secure seal on all side edge laps.

It is used to provide a water and water vapour barrier in all forms of construction. When installed and applied correctly, the system provides a Type A barrier protection system in accordance with BS 8102 – Table 1 and provides levels of protection for grades 1, 2 and 3 in accordance with BS 8102 – Table 2. Under normal conditions of use, Triton TWS/EX 100 will provide a water and water vapour barrier for the life of the building.

Features and benefits:

  • Factory controlled thickness.
  • Rapid sealing and bonding.
  • Fast and easy application.
  • No heating or drying.
  • Self-sealing to minor damage.
  • Selvedge strip to promote immediate lap sealing.
  • High puncture resistance.
  • High joint resistance to water pressure and water vapour transmission.

Applications:

  • Foundations.
  • Basements.
  • Roofs and plaza decks.
  • Lift shafts, pits.
  • Service reservoir roofs.
  • Car parks.
  • Subways.
  • Bathrooms.
  • Balconies.

General information
Specification data - Plastics sheets
Product Reference

Triton TWS/EX 100

Standard product features

Thickness:

1.5 mm.

Roll size (w x l):

1.05 x 19.05 m.

Technical properties:

  • Weight: 1.7 kg/m².
  • Puncture resistance (to ASTM E154): 230 N.
  • Elongation (to ASTM D1000): 300%.
  • Membrane strength (to ASTM D1000): 5 N/mm.
  • Peel strength (to ASTM D1000): 4 N/mm.
  • Water vapour transmission (to ASTM E96): 0.30 g/m²/day.
