TRITON Monopitch Polycarbonate Canopies

Name: TRITON Monopitch Polycarbonate Canopies
Brand: urbanspec
SKU: 2K6A4VuD8JBMK2M18yMe4F

Verified by manufacturer 19 days ago

TRITON Mono Canopies deliver cost-effective covered space and walkways for use in all weathers, that can be further enhanced with glass or polycarbonate vertical cladding for more exposed locations.

Jump to:

01227 200404 Website

Application

Suitable for a wide range of uses including classroom canopies, covered dining and social space, servery canopies, covered walkways, entrance canopies, cycle shelters and waiting areas.

Description

TRITON Mono canopy structures from Streetspace provide a cost-effective option in the polycarbonate canopies range. Achieving clear spans of up to six metres between supports, the TRITON Mono is suitable for a wide range of uses.

TRITON canopies are based around a modular design theme, providing a consistent aesthetic and efficient cost structure with the flexibility for specific site requirements and constraints.

The standard roof specification is the advanced multiwall polycarbonate providing a bright atmosphere without glare, with an aluminium glazing system ensuring a reliable and easy to maintain roof cover for the long term.

Features and benefits:

Designed and manufactured in accordance with BS EN 1090 EXC 2 accreditation.
Offers outstanding durability from an all-steel frame with polyester powder-coat finish, multiwall polycarbonate roof panels, aluminium glazing system and galvanized steel rainwater goods.
Multiple roofing options including polycarbonate and steel sheeting.
The roof pitch and column positions can be adjusted to suit adjacent building design.
25 year structure and 15 year roof covering warranties, with aftercare packages available for periodic inspection and cleaning.
Can be further enhanced with glass or polycarbonate vertical cladding for more exposed locations.

General information

Color	Blue Black Brown Grey Green Orange Yellow Red White Other Guidance for specification option: RAL colour for frames if polyester powder-coated. Show more
Finish	Powder-coated Galvanized
Material	Steel Polycarbonate Glass
Shape	Other
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	15 year Guidance for specification option: Structure warranty. 25 year Guidance for specification option: Roof warranty.

Uniclass	Pr_20_65_78_58 Open-sided sheltersPrimary
CAWS	B91/385 Shelter B91/330 Canopy

Specification data - Open-sided shelters

Description	Open-sided shelter.
Manufacturer	Urbanspec.
Shelter description	Canopy shelter based around a modular design theme.
Dimensions	-
Plan size	- Manufacturer guidance Standard bay widths are 2 m, 3 m and 4 m, but any width from 1 m to 6 m as clearspan structures can be achieved as bespoke design. Wider spans can be achieved using intermediate columns. There is no limit on the length of TRITON canopies. Standard bay lengths are 3.0 m and 4.0 m with variations within the structural design achievable to avoid doorways, access routes or underground services. Contact manufacturer for details and inset requirements.
Height	- Manufacturer guidance Contact manufacturer for details and insert requirements.
Frame	-
Material	Steel.
Finish	Polyester powder-coated. Guidance for specification option: As standard. Colours selected from a basic range or from the RAL colour selector. Contact manufacturer for details. Hot dip galvanized. Guidance for specification option: Specified for the harshest environments where a decorative finish is not required.
Colour	Galvanized. Guidance for specification option: Hot dip galvanized. RAL colour. Guidance for specification option: Insert requirements only when specified with polyester powder-coated finish.
Roof covering	Multiwall polycarbonate. Guidance for specification option: Offering a good balance of light transmission and minimal glare. Optional coloured polycarbonate can be specified. Contact manufacturer for details. Toughened and laminated glass. Guidance for specification option: Utilizing an aluminium glazing bar system. All roof glazing panels are toughened and laminated with optional interlayer tints for shading. Profiled steel sheet. Guidance for specification option: Available in a range of standard top coat colours with white underside. Biodiverse green roof. Guidance for specification option: Available as sedum only or sedum and wildflower. The lightweight system has a steel decking liner, EPDM membrane liner, composite drainage reservoir mat, growing substrate and a pre-planted vegetation mat.
Openings	-
Windows	Not required. Solid polycarbonate. Multiwall polycarbonate. Aluminium glazed curtain walling. Planar glass.
Rainwater drainage	Not required. Guttering. Guidance for specification option: Designed with integral steel guttering, colour powder-coated to match the canopy steel frame for long term durability and ease of maintenance. Downpipes. Guidance for specification option: Aluminium downpipes custom manufactured for each canopy with integral connections for maximum durability. Colour powder-coated finishes match the guttering and steel frame.
Accessories	Not required. Lighting. Guidance for specification option: Various lighting solutions are available to extend safe use outside of daylight hours. IR heaters. Guidance for specification option: External grade radiant electric heaters can be fitted to TRITON canopies to provide warmth in colder weather. Timber post cappings. Guidance for specification option: Timber post cappings can help soften the appearance of a steel frame structure. Post protection pads. Guidance for specification option: Foam protector pads with heavy duty PVC covers can be fitted to canopy posts for structures situated in play areas.

Mounting	Free standing. Guidance for specification option: As standard. Cantilevered structures. Wall mounted. Guidance for specification option: Providing the wall meets the appropriate structural requirements. Contact manufacturer for details.

Sustainability data

Country of product manufacture	United Kingdom
Material	Steel Polycarbonate Glass
Manufacturing plant location	Spicer House, Lympne Industrial Park, Lympne, Hythe CT21 4LR, UK
Recyclability	All non-production steel is 100% recycled and separated at source from fabrication and sheet metal processes. All timber cladding products are sustainably sourced and certified with non-production material separated at source for 100% recycling.
Expected Life	25 year
