TRC Replacement Glass with vacuum glazing - Restoration
Verified by manufacturer 7 days ago
Timber sash window and casement window glass replacement.
Application
Suitable for timber sash windows and casement windows.
Description
Glass replacement for timber sash windows and casement windows. Slim vacuum-glazed units improve security, acoustics and thermal performance.
Ultra-slim vacuum-glazing provides top performance, while retaining the elegance of the original windows.
Features and benefits:
- Ultra-slim, sealed vacuum-glazed units.
- Fits into most single-glazed openings.
- 0.7–1.2 W/m²·K whole window U-values.
- Thermal performance meets Approved Document L.
- Up to Fifteen-year guarantee on glazing unit.
- Replace the original glass with vacuum-glazing, the thickness of single glazing and warmth of triple glazing.
- Elastic dry glazing sealant for durability.
General information
Color | Black Brown Cream White Other |
Finish | Painted Primed Stained |
Material | Wood Timber Glass |
Shape | Other Square Circle Trapezium Triangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year Guidance for specification option: Terms and conditions apply. Five year Guidance for specification option: Terms and conditions apply. Manufacturer guidanceGuarantee Statement We stand by the quality and durability of our [product/service]. That’s why we are proud to offer a [5-year / 10-year Guarantee]. If within this period your [product/service] develops a fault due to materials or workmanship, we will repair or replace it at no additional cost. This guarantee is a reflection of our confidence in the long-lasting performance of our products and our commitment to your satisfaction. Terms and conditions apply. |
Uniclass | |
CAWS | L10/10 Wood windows L10/210 Wood windows |
Specification data - Wood window units
Classification data | |
Standard | To EN 1279. |
Dimensions and configurations | Manufacturer guidanceBespoke; consult manufacturer and insert requirements. Maximum sizes may vary depending on glazing thickness and type required, consult manufacturer. |
Product performance | |
Durability | |
Operation and strength characteristics | See Sapphire Glass Declaration of Performance. |
Loadbearing capacity of safety devices | See Sapphire Glass Declaration of Performance. |
Safety | |
Security level | See Sapphire Glass Declaration of Performance. |
Environmental | |
Frame:glazing ratio (maximum) | Guidance for specification option: Consult manufacturer for details and insert requirements. |
Background ventilation | Guidance for specification option: Only applicable if adding trickle vents to existing windows as specified. Consult manufacturer and insert requirements. |
Acoustic performance rating | 31 dB Rw (typical vacuum unit). Manufacturer guidanceValues up to 38 dB Rw are available with specialist acoustic glazing units; consult manufacturer for details. |
Thermal | |
Whole window U-value | 0.7–1.1 W/m²K. |
Frame | |
Profile | Guidance for specification option: Consult manufacturer for options and insert requirements. |
Wood species | Hardwood. Accoya. Engineered wood. Other. Guidance for specification option: Any other wood species available. Consult manufacturer and insert requirements. |
Chain of custody | FSC. |
Finish as delivered | Guidance for specification option: Consult manufacturer for options and insert requirements. |
Preservative treatment to wood components | Preservative threated. |
Glazing or infill | |
Standard | Relevant parts of BS EN 1279. |
Requirements | Special order. Guidance for specification option: Insert requirement, available with laminated layers including heritage glass or thicker glass. |
Sealant | Elastic sealing compound Repair Care Dry Seal™ MP. Guidance for specification option: It has superb elasticity, even after years in situ. It is available in a choice of finishes and can be overpainted. The result is a superior, long-lasting, effective seal which will protect the window for years to come. |
Sealant finish | Guidance for specification option: Insert requirement, consult with manufacturer for information. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Material | Wood Timber Glass |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/kg) Stage:A1–A3 ('Production stage') Normalised unit : 0.5 (kg CO₂ eq/kg) Declared unit : 0.5 Lower emissions | |
Recyclability | Yes |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
