Name: Traditional Flush Casement Timber Windows - Direct Glazed
Brand: ex89rNU9w9mmKNZbsrYZ89
SKU: 79zw7djzjbkp2xbyvSfoSC

Uniclass 2015

Product Reference

Configuration

Frame (w x d)

Sill section (h x d)

Sill projection

Windowboard groove

For cleaning from the inside of the room with build in restrictor.

Flying mullion

Internal Glazing Bars and/or Perimeter Bead

External Glazing Bars

4 mm tough/ 16 mm argon/ 4 mm tough low-E.

6.8 mm sound control laminated/ 14 mm argon/ 4 mm tough low-E.

Insert requirement; safety, obscured, acoustic or solar control glass options available.

Perimeter/Integral spacer bar

Selected Croft ironmongery with bespoke finish is available; consult manufacturer and insert requirement.

SecurityRating

Trickle ventilation

Child restrictor

ProductInformation

Standard product features

Product Options

Certified to

Alu Clad Tilt & Turn Windows – Side Tilt & Turn Next To Direct Glazed

Size	630 x 1050 mm
Material	Engineered redwood - standard, engineered hardwood, accoya, european oak
Finish	Three coat spray applied factory finish using water based micro-porous paint/ stain
Color	Colour from RAL classic range - standard, dual finish or stain - optional
Features	Outward opening, top or side hung, can be supplied fully reversible, triple glazing available, internally mounted beading
Shape	Rectangle
Uniclass 2015	Wood window units (Pr_30_59_98_96)Primary

Product Reference	Traditional Flush Casement Timber Windows
Size	630 x 1050 mm
Configuration	Open-out, side hinged Open-out, top-hung
Material	Engineered redwood - standard, engineered hardwood, accoya, european oak
Frame (w x d)	56 x 90 mm Standard. 56 x 100 mm
Sill section (h x d)	56 x 90 mm Standard. 56 x 100 mm
Sill projection	50 mm 60 mm 70 mm 80 mm 90 mm 100 mm 110 mm
Horns	Not required As drawing
Windowboard groove	Required Not required
Finish	Three coat spray applied factory finish using water based micro-porous paint/ stain
Hinges	Concealed side hung egress/ easy clean friction hinge with 90° opening Concealed side hung easy clean friction hinge with 60° opening Concealed top swing friction hinge Concealed top swing fully reversible For cleaning from the inside of the room with build in restrictor. Direct glazed Fixed sash Side hung butt hinges
Flying mullion	Required Not required
Profile	Ovolo frame Square frame Standard.
Internal Glazing Bars and/or Perimeter Bead	18 mm lambs tongue type 2 18 mm ovolo profile type 2 22 mm lambs tongue type 1 22 mm ovolo profile type 1 22 mm splayed profile type 1
External Glazing Bars	18 mm chamfered putty bar 22 mm chamfered putty bar 22 mm splayed profile
Glass units	24 mm double glass unit 4 mm tough/ 16 mm argon/ 4 mm tough low-E. 24.8 mm sound control double glazed unit 6.8 mm sound control laminated/ 14 mm argon/ 4 mm tough low-E. Special order Insert requirement; safety, obscured, acoustic or solar control glass options available.
Perimeter/Integral spacer bar	Black warm edge perimeter spacer and integral glazing bars within unit cavity Matt chrome warm edge perimeter spacer and integral glazing bars within unit cavity White warm edge perimeter spacer and integral glazing bars within unit cavity
Ironmongery	Black locking casement handle Brass locking casement handle Polished locking chrome casement handle Satin chrome locking casement handle Special order Selected Croft ironmongery with bespoke finish is available; consult manufacturer and insert requirement.
SecurityRating	Not required PAS 24
Trickle ventilation	Not required Required
Child restrictor	Not required Concealed child restrictor

ProductInformation	https://www.trcwindows.co.uk/professional-commercial-windows-doors/traditional/flush-casement-windows
Standard product features	Finish: Three coat spray applied factory finish using water based micro-porous paint/ stain. Frame: 56 x 90 mm (w x d), manufactured using mortise and tenon joints, glued and mechanically fixed. Sash: 46 x 68 mm. Wood moisture content: 12–19%. Glazing beads: Internally beaded. Sill: Solid hardwood. Fittings: A locking casement fastener to each operable sash. Mechanism: Sashes are hung and operated on the friction hinges and locked by espagnolette locking system. Weather seal: The window is fully weather sealed to BS EN 6375-1. Performance: U-value (to BS EN ISO 10077-1): ≥1.2 W/m²K. Air permeability (to EN 1026:2000): Class 2. Water tightness (to EN 1027:2000): Class 7A. Wind resistance (to EN 12211:2000): Class C5.
Product Options	Finish: Three coat spray applied factory finish using water based micro-porous paint/ stain. Trickle ventilation: Surface mounted, 1700 mm², 4400 mm² or 5000 mm² equivalent area. Child restrictor: Child safety catch type restrictor.

Platform	Compatible	Version	Certified to
IFC	-	1	2.1
Revit	Revit 2017	1	2.1

Traditional Flush Casement Timber Windows - Direct Glazed

630 x 1050 mm

Engineered redwood - standard, engineered hardwood, accoya, european oak

Three coat spray applied factory finish using water based micro-porous paint/ stain

Colour from RAL classic range - standard, dual finish or stain - optional

Outward opening, top or side hung, can be supplied fully reversible, triple glazing available, internally mounted beading

Rectangle

Traditional Flush Casement Timber Windows

630 x 1050 mm

Open-out, side hinged

Open-out, top-hung

Engineered redwood - standard, engineered hardwood, accoya, european oak

56 x 90 mm

56 x 100 mm

56 x 90 mm

56 x 100 mm

50 mm

60 mm

70 mm

80 mm

90 mm

100 mm

110 mm

Not required

As drawing

Required

Not required

Three coat spray applied factory finish using water based micro-porous paint/ stain

Concealed side hung egress/ easy clean friction hinge with 90° opening

Concealed side hung easy clean friction hinge with 60° opening

Concealed top swing friction hinge

Concealed top swing fully reversible

Direct glazed

Fixed sash

Side hung butt hinges

Required

Not required

Ovolo frame

Square frame

18 mm lambs tongue type 2

18 mm ovolo profile type 2

22 mm lambs tongue type 1

22 mm ovolo profile type 1

22 mm splayed profile type 1

18 mm chamfered putty bar

22 mm chamfered putty bar

22 mm splayed profile

24 mm double glass unit

24.8 mm sound control double glazed unit

Special order

Black warm edge perimeter spacer and integral glazing bars within unit cavity

Matt chrome warm edge perimeter spacer and integral glazing bars within unit cavity

White warm edge perimeter spacer and integral glazing bars within unit cavity

Black locking casement handle

Brass locking casement handle

Polished locking chrome casement handle

Satin chrome locking casement handle

Special order

Not required

PAS 24

Not required

Required

Not required

Concealed child restrictor

https://www.trcwindows.co.uk/professional-commercial-windows-doors/traditional/flush-casement-windows

Finish:Three coat spray applied factory finish using water based micro-porous paint/ stain.Trickle ventilation:Surface mounted, 1700 mm², 4400 mm² or 5000 mm² equivalent area.Child restrictor:Child safety catch type restrictor.

Finish:
Three coat spray applied factory finish using water based micro-porous paint/ stain.
Trickle ventilation:
Surface mounted, 1700 mm², 4400 mm² or 5000 mm² equivalent area.
Child restrictor:
Child safety catch type restrictor.
