Toberloc

Application

For block paving applications, including heavy duty use.

Description

L-shaped concrete paving block. The shape ensures each block is always anchored, giving maximum resistance to rutting and lateral forces and avoiding creep.


Toberloc is produced with integral spacers to maintain uniform joints ready for machine laying and is an economic choice for larger paving projects.

General information

Material

Concrete

Size

225 x 225 x 80 mm

Uniclass 2015

Pr_25_93_60_19 Concrete paversPrimary
Pr_25_93_60_19 Concrete paversPrimary

CAWS

Q24/10 Conventional concrete block paving

Q24/110 Conventional concrete block paving

Q24/112 Conventional concrete block paving with bound base

Q24/113 Conventional concrete block paving overlay

Specification data - Concrete pavers Enhanced data

Standard

To BS EN 1338.

Physical properties

-

Colour

Brindle.

Charcoal.

Natural.

Finish

Hard-wearing surface layer, at least 4 mm thick with more than 350 kg/m³ cement

-

Profile

-

Paver type

Regular plan form.

Dimensions and associated tolerances

-

Nominal sizes

225 x 225 x 80 mm.

Slip resistance

Extremely low (>75 USRV).

Skid resistance

Extremely low (>75 USRV).

Product Reference

Toberloc

Strength

>3.6 MPa.

Efflorescence

Minimum 12 hour vapour curing to reduce significantly the possibility of efflorescence.

EnergyUsed

100%.

WaterUsed

100%.

CarbonFootprint

0.0

Manufacturing location

Produced in the UK with locally sourced materials.

BREEAM rating

B or A with recycled sub-base.

Environmental information

Country of material origin

United Kingdom

Recyclability

100%
