Tilt And Turn Window 70 mm

Tilt And Turn Window 70 mm

Liniar Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

PVC-U tilt and turn window.

Jump to:
+44 (0)1332 883900 www.liniar.co.uk

Description

Offering a greater scope for larger openings than a traditional casement window, tilt and turn windows are ideal for high-rise as well as low-rise applications, and thermal performance is helped by the larger panes of glass. Ideal for fire escapes, the windows are available in 'tilt before turn' or 'turn before tilt' options.

Features and benefits:

  • Patented co-ex bubble gasket.
  • Thermally efficient.
  • 100% lead-free PVC-U.
  • Easy to install.
  • Ten year profile guarantee.
  • Slim sightlines.

Accreditations:

BS EN 12608:2003.

General information

Uniclass 2015

Pr_30_59_98_92 Unplasticized polyvinyl chloride (PVC-U) window unitsPrimary

CAWS

L10/30 PVC-U windows

L10/350 PVC-U windows

Specification data - Unplasticized polyvinyl chloride (PVC-U) window units

Product Reference

Tilt And Turn Window 70 mm

Configuration

Tilt before turn

Turn before tilt

Frame

-

Profile

Chamfered

Sculptured

Outer frame

57 mm

77 mm

Transom

67 mm

87 mm

External sill

85 mm

150 mm

165 mm

180 mm

225 mm

Glazing

Double

28 mm, U-Value of 1.3 W/m²K achievable, consult manufacturer.

Triple

36 mm, U-Value of 0.9 W/m²K achievable, consult manufacturer.

Colour

7016 grey

Available with sculptured profile only.

Black

Chartwell green

Available with sculptured profile only.

Cream

Available with sculptured profile only.

Cream foil

Available with sculptured profile only.

Golden oak

Irish oak

Available with sculptured profile only.

Mahogany

Rosewood

White

Available with sculptured profile only.

White foil

Available with sculptured profile only.

Glazing flipper

Not required

Required

Thermal dam

Not required

Required

Georgian bars

Not required

Required

Product Options

Colour:

Other colours are available as a special order, consult manufacturer.

Glazing flipper:

Creates a thermal barrier and additional gasket for even higher energy efficiency.

Thermal dam:

Creates a multi-chambered barrier to prevent heat loss at the outer edge of the frame.

Third party certifications

  • 10/4772
