Tile Bathroom Wall Panels - Waterproof Composite Bathroom Wall Panel
Verified by manufacturer 27 days ago
Our Tile collection has been made from a specially formulated composite material to ensure it is 100% waterproof.
Application
Suitable for use in bathrooms around shower and bath units.
Description
Tile shower panels are a decorative, composite tile effect (embossed) bathroom wall panel used for creating a water-resistant wall covering around a shower or bath.
Features and benefits:
- 100% water-resistant.
- Easy to clean with no grout.
- Range of tile colours.
- Square edge.
- Trims and endcaps are available.
- Suitable layouts include: Vertical and Horizontal panels, for shower/ bath combination.
- A lifetime warranty*
*Warranty is validated, provided the product has been installed as per the installation instructions.
General information
Color | Grey Brown Beige White Black |
Finish | Other |
Material | Composite |
Shape | Rectangle |
Length | 2400 mm |
Width | 600 mm 1200 mm 2400 mm |
Height | 3 mm |
Warranty description | Lifetime |
Uniclass | |
CAWS | N13/355 Baths N13/375 Shower units K13/160 Proprietary N10/10 Purpose-made N10/110 Purpose-made K13/160 Proprietary |
Specification data - Compact or solid grade high-pressure laminate (HPL) boards
Classification data | |
Grade | HPL/ BS EN 438-2, vertical. HPL/ BS EN 438-2, horizontal. |
Fire performance | To EN 13501, B-s2, d0. |
Thickness | 3 mm. |
Panel size | |
Length | 2400 mm. |
Width | 600 mm. 1200 mm. |
Edges | Square. |
Finish | Gloss. |
Colour | Black. Grey. Navy. Moss. Mocha. Blush. White. Pure white. |
Core | Compact HPL core. |
Facing | Decorative compact HPL. |
Impact resistance | To EN 438-2, ≥1800 mm. Guidance for specification option: Impact resistance (Large diameter ball) (Drop height for ≤10 mm diameter imprint). |
Abrasion resistance | To EN 438-2, unicolour: ≥150 revolutions and printed decor: ≥125 revolutions. |
Scratch resistance | To EN 438-2, ≥2 N (smooth finish) and ≥3 N (textured finish). |
Stain Resistance | To EN 438-2, Group 1 and 2: ≥5 and Group 3: ≥4. |
Colour fastness | To EN 438-2, ≥4–5 grey scale. |
Accessories | Not required. End cap. Internal corner. External corner. Bottom floor trim, PVC white. Shower niche. Cover shelving. Adhesive. Sealant. |
Colour | Polished silver, aluminium. Black, PVC. White, PVC. |
Formaldehyde emissions | To EN 438-7, E1. |
Sustainability data
Material | Composite |
Literature
Literature type
Wetwall brochure
Tile Shower Panels - Technical Data Sheet
