Thermally Modified Radiata Pine Cladding - Timber Cladding

Verified by manufacturer 4 months ago

Hector WB10 (145 x 20 mm)

NORclad Limited Variant:

Thermally Modified Cladding available uncoated or factory coated

Jump to:
+44 (0)1275 794735 Website

Application

Suitable for use in horizontal and vertical cladding scenarios.

Description

Created from thermally modified New Zealand plantation timber. A fine sawn face or textured face allows a depth of grain, and optimal coating performance.


The thermal modification process means enhanced stability, reduced resin content, is a beautiful homogeneous brown colour, and is naturally durable so does not require any chemical preservatives.


Features and benefits:

  • Wood species: Thermally Modified Radiata Pine (Pinus Radiata).
  • Durability Class 2
  • Available in a range of architectural profiles and can be supplied factory coated.
  • The range offers a renewable alternative to some of the more traditional Larch or Cedar cladding that the construction market are used to.
  • FSC certified plantation timber. This combined with the Thermal modification process permanently changes both the chemical, and physical properties of the timber.


General information

Color

Manufacturer guidance

As per manufacturer. UK standard stock colours. Colours presented are in Protector – Water Borne and are indicative only. Colour may change/ fade as a part of the natural weathering process.

Finish

Textured

Manufacturer guidance

As per manufacturer and includes:

  • Fine band sawn.
  • Riven.
  • Ribbed.

Material

Wood

Guidance for specification option:

Thermally Modified Radiata Pine (Pinus Radiata).

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

15 year

Guidance for specification option:

Against fungal decay (subject to terms and conditions).

30 year

Guidance for specification option:

Or more when maintained according to manufacturer’s recommendations.

Uniclass

Pr_25_71_97_84 Softwood weatherboardsPrimary
Pr_25_71_97_55 Modified wood weatherboards

CAWS

H21/116 Horizontal timber weatherboarding

H21/115 Vertical timber weatherboarding

H21/111 Horizontal timber weatherboarding

H21/110 Vertical timber weatherboarding

H21/15 Horizontal timber weatherboarding

H21/10 Vertical timber weatherboarding

Specification data - Softwood weatherboards

Standard

To CE EN 14915 Grade A.

Thermal conductivity

0.099 W/m·K (Thermal conductivity is reduced by 20-25% compared with Radiata Pine).

Wood species

Thermally modified Radiata Pine (Pinus Radiata).

Quality of timber (exposed surfaces)

To CE EN 14915 Grade A for use as claddings and BS 1186:3 1990 Grade CSH and BS EN 942 Grade J5 for use in joinery.

Guidance for specification option:

Front face and edges virtually free of any defects but with

one edge knot and one small face defect allowed per piece in 20% of boards only. Back side with some defects allowed.

Profile

Vertical/ horizontal.

Manufacturer guidance

All cladding profiles are manufactured in accordance with BS 8605-1:2014, External Timber Cladding.


Timber used is equivalent to BS EN942 Grade J5/ CE EN14915 Grade A.

Finished size

-

Face width

125 mm cover.

Thickness

20 mm.

Biological durability

-

Use class

To EN 350-1, Class 1.

Preservative treatment

15 years against fungal decay (subject to terms and conditions).

30 years or more when maintained according to manufacturer’s recommendations.

Flame-retardant treatment

None.

Fire treated to Euroclass B-s2-d0 (s2 Smoke Production – d0 Flaming Droplets). BS EN 13823 & BS EN 11925-2 Single Burning Item Equivalent to UK “Class O” BS 476: Part 6 & BS 476: Part 7.

Length

Solid lengths from 2.4–4.8 m.

Finger jointing available up to 12 m.

Manufacturer's option.

Guidance for specification option:

Product is supplied as standard in ‘random length’ or otherwise lengths at the manufacturer's option. Specified fixed lengths may be available but are subject to

conditions including minimum quantity, price premium and availability. Please check with the manufacturer prior to placement of order.

Finish

Fine band sawn.

Guidance for specification option:

(some variation in the visual appearance of the bandsawn finish can be expected).

Riven.

Ribbed.

Colour

Vulcan Nero.

Vulcan Walnut.

Vulcan Graphite.

Vulcan Teak.

Vulcan Patina.

Show more

Manufacturer guidance

As per manufacturer. UK standard stock colours. Colours presented are in Protector – Water Borne and are indicative only. Colour may change/ fade as a part of the natural weathering process.

Applied finish

Exterior wood stain.

Guidance for specification option:

Recommends at least one coat of Protector Oil or proprietary specified wood stain to be applied to all sides prior to installation and then a further one or two coats applied once boards are fixed in place according to manufacturer’s instructions. Thoroughly seal all exposed ends.

MoistureContent

Approximately 7% (±2%) at time of dispatch. Moisture content may vary depending on environment.

Dimensional movement

Manufacturer's standard.

Manufacturer guidance

Expected dimensional change in structure*:

  • Tangential: 2%.
  • Radial shrinkage: 2.5%.
  • Longitudinal: 0.25%.

*based on 7% MC to fibre saturation point.

Average density

420 kg/m³.

Hardness

Low (2.5 kN Janka).

Weight

11 kg/m².

Sustainability data

Country of material origin

New Zealand

Material

Wood

Guidance for specification option:

Thermally Modified Radiata Pine (Pinus Radiata).

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

0 %

Literature

Certificate of Registration ISO14001

Certificate of Registration ISO14001

Certificate of Registration ISO9001

Certificate of Registration ISO9001

NORclad Digital Brochure (Cladding)

NORclad Digital Brochure (Cladding)
