Liquid applied flexible polymer for sealing penetrations around pipes, cables, and conduits.
Product Application – The Goat® Airtight Flexible Sealant
Apply in accordance with manufacturer’s written instructions to maintain continuity of the airtight and vapour control layer.
The sealant shall be installed to provide a continuous, flexible and durable seal at all service penetrations and junctions within the building envelope.
Suitable Applications
Substrate Preparation
Substrates shall be:
Where gaps are present, ensure voids are appropriately filled or supported prior to sealant application.
Application Conditions
Installation
The cured sealant shall form a flexible, airtight and waterproof barrier capable of accommodating thermal and structural movement.
Integration with Airtight Systems
The Goat® shall be installed to ensure full integration with adjacent liquid membranes, vapour control layers and air barrier systems.
Particular attention shall be given to:
Completed works shall maintain airtight continuity in preparation for air pressure testing.
The Goat – Airtight Flexible Sealant
Product Description
The Goat is a high-performance, liquid-applied flexible sealant engineered to provide complete airtight and waterproof sealing around service penetrations and junctions in the building envelope. It is a reactive polymer-based sealant that cures to form a resilient, elastic barrier capable of expanding and contracting with structural movement while maintaining long-term performance.
Designed for use around penetrations such as pipes, cables, conduits and other services passing through walls, floors and ceilings, The Goat eliminates common leakage points that compromise energy performance and airtightness continuity. Its flexibility and adhesion across a range of substrates ensure a durable, seamless seal to support high-performance building standards.
Key Features and Benefits
Typical Applications
The Goat is suitable for sealing:
It ensures airtight continuity in both internal and external conditions where durable sealing and flexibility are critical.
Benefits for Airtight Design
The Goat provides a reliable sealing solution at critical junctions that are often prone to failure in airtight systems. Its elastic performance helps maintain airtight continuity in areas of movement without compromising long-term durability or performance
Color | Green Black White |
Finish | Other |
Material | Polymer |
Shape | Formless |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | N11/50 Sealant N11/390 Sealant N12/470 Sealant N12/470 Sealant N10/80 Sealant N10/460 Sealant |
Classification data | |
Standard | To EN 14891 and EN 1504-2. |
Material | Polymer. |
Colour | Green. Black. White. |
Form | Liquid. |
Setting time | 60 minutes (initial setting); 120 minutes (final setting). |
Adhesion | >0.5 N/mm². Guidance for specification option: On concrete. |
Density | 1.4 kg/L. |
Solids | 100%. |
Elongation | >400%. |
Tensile strength | 0.7 N/mm². |
Hardness (shore A) | 40–50. |
Crack bridging | 2 mm. Manufacturer guidanceCrack bridging after 500 hours. |
Waterproofing | To EN 14891, Pass. Positive and negative water pressure to EN 1504-2, >2.5 bar. |
Application temperature range | +5 to +40°C. |
VOC content | VOC free. |
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Manufacturing plant location | |
Material | Polymer |
Recyclability | Not recyclable due to its adhesion to other products |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 0 % |
Expected Life | 25 year |
