Tessera Struktur 2 - Tufted carpet tile

Name: Tessera Struktur 2 - Tufted carpet tile
Brand: Forbo Flooring Systems
SKU: 8zhpKMp3ydqUHjRVaKXtCZ

Verified by manufacturer 12 days ago

Third party certifications:

Subtle, compact, flat structured microtuft carpet tile available in a palette of 6 tonal stripe options.

Jump to:

Application

Suitable for heavy traffic areas of buildings such as corridors and reception areas.

A compact, flat structured 50 x 50 cm carpet tile, manufactured from 100% solution dyed polyamide 6 for class 33 durability and colour fastness.

Features and benefits:

350 gsm pile weight, creating a durable authentic flatweave texture.
50 x 50 cm tile format laid quarter turn (monolithic installation is at the discretion of the user, but non-visible joins are not guaranteed).
65% recycled content by weight.
Acoustic value 17 dB for reduced noise transmission.
Meets requirements of EN 14041.

Color	Black Brown Grey Beige
Finish	Tufted
Material	Polyamide Guidance for specification option: Modified bitumen; 100% polyamide 6.
Shape	Square
Length	500 mm
Width	500 mm
Height	5.1 mm
Warranty description	Ten year

Uniclass	Pr_35_57_11_62 Pile carpet tilesPrimary
CAWS	M50/15 Carpet tiling M50/130 Carpet tiling

Style	Microtuft.
Material	100% polyamide 6.
Classification	-
Standard	To EN 1307 and 14041.
Level of use class	Class 33. Guidance for specification option: Heavy contract.
Recycled content	65.42%.
Size	500 x 500 mm.
Colour and pattern	4400 Grå+Måne. 4401 Järn+Grå. 4402 Svart+Järn. 4403 Kaffe+Korn. 4404 Malm+Kaffe. 4405 Järn+Malm.

Total thickness	5.1 mm ±10%. Guidance for specification option: ± 10%.
Total weight	3765 g/m². Guidance for specification option: ± 10%.
Castor chair use (to BS EN 985)	Minimum R-value: ≥ 2.4.
Ska Rating	Struktur 1 meets Ska Rating criteria for M12 soft floor coverings in office, retail and higher education schemes.
Impact sound reduction	17 dB.
Pile composition	100% polyamide 6.
Dye method	100% solution dyed.
Stitch density	126 080 per m².
Pile weight after shearing	350 g/m² 10%.
Adhesive	Not required; 542 Eurofix Tack Plus solvent free release system. IOBAC MagTabs®.
Light fastness (to BS EN ISO 105 B02)	≥ 6.
Dimensional stability (to BS EN 986)	≤ 0.2%.
Reaction to fire (to EN 13501-1)	CfI-s1.
Slip resistance (to EN 13893)	DS: ≥ 0.30.
Pile height above backing	1.00 mm ±0.5 mm.
Primary backing	Polyester.
Secondary backing	ProBac™ modified bitumen and polyester fleece.
Body Voltage (to EN 1815)	Pass (<2 kV).
Edging	Not required. As per 740.

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Polyamide Guidance for specification option: Modified bitumen; 100% polyamide 6.
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	7.06 kg CO₂ eq/m² Self declared
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	65 %
